Accessories for

kWh metering

3

CKM
Upgrade kit for installing meter panel
MPF 25/63 B in accessory cabinet CDCA
or in low-profile meter cable enclosures.

MPF 25/63 B
Meter panel with terminal block.

PBKP 25/50
Seal cover for KSKP 25/50.

Designation ID No. Description Rated Number of Dimensions Weight
current modules Height Width Depth
A M * mm kg/pcs
MPF 25 B 2CGX0 53310737 Meter panel including 25 17 570 220 115 5.0
terminal block KSKP 25
MPF 63 B 2CGX0 53310738 Meter panel including 63 17 570 220 115 5.0
terminal block KSKP 50
CKM 2CGX0 53390034 Upgrade kit – – – – – 0.02
PBKP 25 2CGX0 53050141 Seal cover – 6 – 80 – 0.1
PBKP 50 2CGX0 53050142 Seal cover – 7 – 96 – 0.1
* One module M = 12.5 mm.
