Introduction
Planning and design program, Connect IT
1
Front view sketch of complete cabinet created in Connect IT.
Connect IT planning software
Connect IT is a Windows®-based planning program for Connect IT offers great scope to freely create any desired
cable distribution cabinets, service distribution boards and combination of switching devices and enclosures. The work
other applications based on the range of switching devices, is done quickly and simply, with the aid of pictures and text.
busbar system and enclosures.
Connect IT is also suitable for use when planning a busbar
Connect IT makes it easy to design an electrical distribution system without enclosure, e.g. for installation in electrical
board and to obtain details of its components as follows: operating areas.
− Enclosures with accessories
− Busbar system Connect IT is available for free download at:
− Switching devices and connectors http://new.abb.com/low-voltage/products/cable-distribution-
− Own hardware added, e.g. fuses cabinets/kabeldon-distribution-boards/connect-it
or contact us.
Connect IT also generates information for ordering, planning
and documentation.
Contact us for further information and to place your order!
− A single-line diagram, to which addresses, cable data and
other details can be added.
− A front view sketch, which can be used as a basis for
component mounting.
