Railway applications, terminal blocks
ADO System IDC and pluggable technologies
®

Feed-through

Section
1.5 mm² D1.5/5.ADO.NF D2.5/8.ADO.NF1
1.82 mm² D1.5/6.ADO.NF
2.61 mm² D2.5/8.ADO.NF
4.32 mm² D4/8.ADO.NF

4

Pluggable Feed-through: 1 ADO - 1 pluggable

Section
1.5 mm² D2.5/7.ADO-CPE.NF1
1.82 mm² D1.5/7.ADO-CPE.NF
2.61 mm² D2.5/7.ADO-CPE.NF
4.32 mm² D4/7.ADO-CPE.NF

Female plugs for pluggable terminal blocks

Section
1.5 mm² L 277 200 15
1.82 mm² L 266 200 15 L 266 200 25
2.61 mm² L 267 200 15 L 267 200 25
4.32 mm² L 276 200 15

Clamp - Channels for jumpering or testing - Test socket - Blown-fuse indicator
