AF190 ... AF370 3-pole contactors with built-in PLC interface

90 to 200 kW
AC / DC operated with 1 N.O. + 1 N.C. auxiliary contacts

Description
AF190 ... AF370 contactors are mainly used for controlling 3-phase motors and power circuits up to
1000 V AC and up to 340 V DC. These contactors are of the block type design with 3 main poles.
– control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage range
(e.g. 100...250 V AC and DC), only 2 coils to cover control voltages between 100...500 V 50/60 Hz and
100...500 V DC
- can manage large control voltage variations
- reduced panel energy consumption
1SFC101165V0001 - very distinct closing and opening
- can withstand short voltage dips and voltage sags (SEMI F47 conditions of use on request).
– built-in surge suppression
– add-on auxiliary contact blocks for side mounting and a wide range of accessories.
AF205-30-11
Ordering details
IEC UL / CSA Rated control Auxiliary Type Order code Weight
Rated operational 3-phase General circuit contacts (1) 5
power current motor use voltage fitted Pkg
θ ≤ 40 °C rating rating Uc min. ... Uc max. (1 pce)
400 V 480 V 600 V AC
AC-3 AC-1
kW A hp A V 50/60 Hz V DC kg
90 275 125 250 100...250 100...250 1 1 AF190-30-11-33 1SFL487002R3311 3.000
250...500 250...500 1 1 AF190-30-11-34 1SFL487002R3411 3.000
110 350 150 300 100...250 100...250 1 1 AF205-30-11-33 1SFL527002R3311 3.000
1SFC101133V0001 132 400 200 350 100...250 100...250 1 1 AF265-30-11-33 1SFL547002R3311 4.640
250...500
1 1
250...500
3.000
1SFL527002R3411
AF205-30-11-34
250...500
AF265-30-11-34
1SFL547002R3411
4.640
250...500
1 1
100...250
160
500
250
400
250...500
1 1
250...500 100...250 1 1 AF305-30-11-33 1SFL587002R3311 4.640
4.640
1SFL587002R3411
AF305-30-11-34
AF370-30-11 200 600 300 520 100...250 100...250 1 1 AF370-30-11-33 1SFL607002R3311 4.640
250...500 250...500 1 1 AF370-30-11-34 1SFL607002R3411 4.640
(1) For other auxiliary contacts arrangements, please contact your ABB local sales organization.
AF190 ... AF370 are equipped with low voltage inputs for control, for example by a PLC.
Control inputs

Main dimensions mm, inches
A
10 0.39" 140 5.51" 195.5 7.70"
SECTION B-B 19.5 0.77" ø 10.5 0.41" 35.5 1.40" 5 0.20"
B 169.5 6.67"
10 0.39" 105 4.13" ø 8.5 0.33" 35.5 1.40" 5 0.20"
83.5 3.29" 29.5 1.16" 94.7 3.73" 33.4 1.31"
196 7.72" 225 8.86"
1SFC101167C0201 - Rev. A

35 1.38" 43.75 1.72" 1SFC101167C0201
AF190, AF205 AF265, AF305, AF370

ABB | 5/105
