AF116 ... AF370 3-pole contactors

with 1 N.O. + 1 N.C. auxiliary contacts
Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

kg
1SFC101071V0001 Side-mounted instantaneous auxiliary contact blocks 1SFN010820R1011 2 0.050
1
AF116 ... AF370
CAL19-11
1
1 1 CAL19-11B 1SFN010820R3311 2 0.050
CAL19-11
Mechanical interlock unit
AF116 ... AF370 VM19 1SFN030300R1000 1 0.054
AF116 ... AF146 and AF190, AF205 VM140/190 1SFN034403R1000 1 0.088
AF190, AF205 and AF265 ... AF370 VM205/265 1SFN035203R1000 1 0.090
Terminal shrouds 5
AF116 ... AF146, with compression lugs LT140-30L 1SFN124203R1000 2 0.070
AF190, AF205, with cable clamps LT205-30C 1SFN124801R1000 2 2 0.050
1SFN124803R1000
LT205-30L
0.220
AF190, AF205, with compression lugs
1SFC101035V0001 AF190, AF205, with shorting bar or between contactor LT205-30Y 1SFN124804R1000 1 0.050
and TOL/EOL in DOL-starters
1SFN125403R1000
LT370-30L
AF265 ... AF370, with compression lugs
0.280
VM19 AF265 ... AF370, with cable clamps LT370-30C 1SFN125401R1000 2 2 0.035
AF265 ... AF370, with shorting bar or between contactor LT370-30Y 1SFN125404R1000 1 0.075
and TOL/EOL in DOL-starters
AF265 ... AF370, for use with extending cable clamps, LT370-30D 1SFN125406R1000 1 0.150
ATK300/2 and OZXB4
1SFC101041V0001 For contactors Dimensions bar Type Order code Pkg Weight
(1 pce)
qty
hole Ø
LT370-30C mm mm kg
Terminal enlargements
AF116...AF146 6.5 13 x 3 LW140 1SFN074207R1000 1 0.115
AF190...AF205 10.5 17.5 x 5 LW205 1SFN074807R1000 1 0.260
AF265...AF370 10.5 20 x 5 LW370 1SFN075407R1000 1 0.340
1SFC101049V0001 Terminal extension 6.5 13 x 3 LX140 1SFN074210R1000 1 1 0.072
AF116...AF146
8.5
17.5 x 5
0.180
1SFN074810R1000
AF190...AF250
LX205
LX140 AF265...AF370 10.5 20 x 5 LX370 1SFN075410R1000 1 0.234
(1) For more information, refer to main catalog "Accessories" section.

1SFC101138C0201

ABB | 5/107
