AF116 ... AF146 3-pole contactors with built-in PLC interface

55 to 75 kW
AC / DC operated with 1 N.O. + 1 N.C. auxiliary contacts

Description
AF116 ... AF140 contactors are mainly used for controlling 3-phase motors and power circuits up to
690 V AC, AF146 up to 1000 V AC and AF116 ... AF146 up to 260 V DC. These contactors are of the block
type design with 3 main poles.
– control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage range
(e.g. 100...250 V AC and DC), only 2 coils to cover control voltages between 100...500 V 50/60 Hz and
100...500 V DC
- can manage large control voltage variations
1SFC101083V0001 - reduced panel energy consumption
- very distinct closing and opening
- can withstand short voltage dips and voltage sags (SEMI F47 conditions of use on request).
– built-in surge suppression
AF146-30-11 – add-on auxiliary contact blocks for side mounting and a wide range of accessories.
Ordering details
IEC UL / CSA Rated control Auxiliary Type Order code Weight 5
Rated operational 3-phase General circuit contacts (1)
power current motor use voltage fitted Pkg
θ ≤ 40 °C rating rating Uc min. ... Uc max. (1 pce)
400 V 480 V 600 V AC
AC-3 AC-1
kW A hp A V 50/60 Hz V DC kg
For connection with built-in cable clamps
1SFC101186V0001 55 160 75 160 100...250 100...250 1 1 AF116-30-11-33 1SFL427001R3311 1.750
250...500
250...500
AF116-30-11-34
1.750
1 1
1SFL427001R3411
200
100...250
100
1SFL447001R3311
200
AF140-30-11-33
1 1
1.750
75
100...250
1.750
AF146-30-11-33
1SFL467001R3311
100...250
100...250
75 225 100 200 250...500 250...500 1 1 AF140-30-11-34 1SFL447001R3411 1.750
1 1
AF146-30-11B 250...500 250...500 1 1 AF146-30-11-34 1SFL467001R3411 1.750
With bar connections
55 160 75 160 100...250 100...250 1 1 AF116-30-11B-33 1SFL427002R3311 1.500
250...500 250...500 1 1 AF116-30-11B-34 1SFL427002R3411 1.500
75 200 100 200 100...250 100...250 1 1 AF140-30-11B-33 1SFL447002R3311 1.500
250...500 250...500 1 1 AF140-30-11B-34 1SFL447002R3411 1.500
75 225 100 200 100...250 100...250 1 1 AF146-30-11B-33 1SFL467002R3311 1.500
250...500 250...500 1 1 AF146-30-11B-34 1SFL467002R3411 1.500
(1) For other auxiliary contacts arrangements, please contact your ABB local sales organization.
AF116 ... AF146 are equipped with low voltage inputs for control, for example by a PLC.
Control inputs
Main dimensions mm, inches
E
E
10 0.39" 90 3.54" 142.5 5.61" 10 0.39" 90 3.54" 142.5 5.61"
D D D D
55.5 0.22" 19.5 4.96" 55.5 2.18" 19.5 0.77"
150 5.91" 150 5.91"
1SFC101166C0201 - Rev. A

30 1.18" 30 1.18" 1SFC101166C0201
AF116, AF140, AF146-30-11 AF116, AF140, AF146-30-11B

ABB | 5/103
