MO5100, MO495, MO496 manual motor starters magnetic only

70 to 100 A – with electromagnetic protection

Description
The manual motor starter magnetic only is used to manually switch on and off motors and to protect them
reliably and without the need for a fuse from short-circuits.
2 Ordering details
Rated Rated Short-circuit Rated instan- Type Order code Weight
(1 pc)
operational operational breaking
taneous short-
MO5100-100 no mirror power 1) current capacity I at circuit current
CS
400 V
setting l
400 V AC
i
AC-3
A
kW
kA
MO5100 manual motor starter magnetic only A kg
MO5100-100
25 70 36 2) 210 ... 770 MO5100-70 1SDA082031R1 1.100
30 80 36 2) 240 ... 880 MO5100-80 1SDA082032R1 1.100
45 100 36 2) 300 ... 1100 MO5100-100 1SDA082033R1 1.100
MO495 manual motor starter magnetic only
37 75 25 975 MO495-75 1SAM560000R1008 2.247
45 90 25 1170 MO495-90 1SAM560000R1009 2.269
55 100 25 1235 MO495-100 1SAM560000R1010 2.292
MO496 manual motor starter magnetic only
37 75 50 975 MO496-75 1SAM590000R1008 2.278
45 90 50 1170 MO496-90 1SAM590000R1009 2.266
ST02601 55 100 50 1235 MO496-100 1SAM590000R1010 2.293

I at 415 V AC
2) 1) For overload protection of motors, an appropriate thermal or electronic overload relay must be used
MO495-75 CS

2CDC241021F0011

MO496-100

Main dimensions mm, inches
101.2 (4P) 83
3.98 3.27
96 12 0.47" 23 0.91" 8 0.31"
3.78 78
38.1 3.07
1.5
25 25 25 70
0.98 0.98 0.98 2.76
4
65 2.56 0.04 1 6.50" 6.10" 1.77" 4.57" 5.91"
14 0.55 16 0.63
130 5.12 1.61 45 1.77
1 41 165 155 45 116 150
0.04
1
0.04 1.1Nm
45
1.77 3 2
71 0.12 0.08 1SDC21000HF0001 7 0.28" 2CDC242016F0011
2.8 30 1.18"
76.2 (3P) 1 101 5 0.20" 132 5.20"
3.0 0.04 3.97 70 2.56" 153 6.02" 2CDC131114C0201
1 169 6.65"
MO5100 MO495, MO496
