AS09..S ... AS16..S 3-pole contactors - with spring terminals

Main dimensions mm, inches

72.5 2.85"
35 1.38"
45 1.77" 7 0.28" 10 0.39" 2 x
M4 8-32 UNC ø 4.2 0.17"
35 mm EN/IEC 60715 5.5 0.22"
68 2.68" 60 2.36" 50 1.97"

AS09..S, AS12..S, AS16..S

110.8 4.36"
6 45 1.77" 72.5 2.85" 10 0.39" 2 x 35 1.38"
7 0.28" M4 8-32 UNC ø 4.2 0.17"
35 mm EN/IEC 60715 5.5 0.22"
68 2.68" 35.4 1.39" 60 2.36" 50 1.97"

AS09..S, AS12..S, AS16..S
+ CA3..S front-mounted 1-pole auxiliary contact block

110.8 4.36"
72.5 2.85" 10 0.39" 35 1.38"
45 1.77" 2 x
7 0.28" M4 8-32 UNC ø 4.2 0.17"
35 mm EN/IEC 60715 5.5 0.22"
68 2.68" 35.4 1.39" 60 2.36" 50 1.97"

AS09...16-30-32S

72.5 2.85"
90 3.54" 7 0.28" 10 0.39" 4 x 80 3.15"
M4 8-32 UNC ø 4.2 0.17"
35 mm EN/IEC 60715 5.5 0.22"
68 2.68" 60 2.36" 50 1.97"

1SBC101414S0201
AS09..S, AS12..S, AS16..S
+ VM3 mechanical interlock unit including two BB3 fixing clips
