AS09 ... AS16 and

ASL09 ... ASL16 3-pole contactors
Main accessories

Front-mounted instantaneous auxiliary contact blocks
For contactors Auxiliary Type Order code Pkg Weight
1SBC101036F0014 kg
qty
(1 pce)
contacts
AS09 … AS16 1 0 CA3-10 1SBN011010T1010 10 0.011
CA3-10 ASL09 … ASL16 0 1 CA3-01 1SBN011010T1001 10 0.011

Front-mounted electronic timer
For contactors Rated control circuit Type Order code Pkg Weight
voltage - Uc
qty
(1 pce)
1SBC101337F0014 ON-delay V kg 4
AS09 … AS16, ASL09 … ASL16 24...240 V AC/DC TEF3-ON 1SBN021012R1000 1 0.065
TEF3-ON
OFF-delay
AS09 … AS16, ASL09 … ASL16 24...240 V AC/DC TEF3-OFF 1SBN021014R1000 1 0.065
1SBC101069F0014 Mechanical interlock unit Type Order code Pkg Weight
For contactors
(1 pce)
qty
VM3 kg
AS09 … AS16, ASL09 … ASL16 VM3 1SBN031005T1000 10 0.002
Surge suppressors
1SBC574001F0301 For contactors Rated control circuit Type Order code Pkg Weight
qty
voltage - Uc
(1 pce)
AS09 ... AS16, V 24...50 AC DC RV5/50 1SBN050010R1000 2 kg
0.015
●
●
ASL09 ... ASL16 50...133 ● ● RV5/133 1SBN050010R1001 2 0.015
RV5
110...250 ● ● RV5/250 1SBN050010R1002 2 0.015
250...440 ● ● RV5/440 1SBN050010R1003 2 0.015
AS09 ... AS16 24...50 ● – – RC5-1/50 1SBN050100R1000 2 2 0.012
1SBC101034F0014 110...250 ● – – RC5-1/250 1SBN050100R1002 2 2 0.012
0.012
1SBN050100R1001
RC5-1/133
50...133
●
250...440
0.012
1SBN050100R1003
RC5-1/440
●
12...32
ASL09 ... ASL16
RT5/65
0.015
25...65 – – ● RT5/32 1SBN050020R1000 2 2 0.015
1SBN050020R1001
●
50...90 – ● RT5/90 1SBN050020R1002 2 0.015
BEA16-3 77...150 – ● RT5/150 1SBN050020R1003 2 0.015
150...264 – ● RT5/264 1SBN050020R1004 2 0.015
Connecting links with manual motor starters
For contactors Manual motor Type Order code Pkg Weight
1SBC101071F0014 AS09 … AS16 MS116-0.16 ... MS116-16 BEA16-3 1SBN081006T1000 10 kg
starter
qty
(1 pce)
0.019
MS132-0.16 ... MS132-16
ASL09 … ASL16
Connection sets for reversing contactors
BER16C-3 For contactors Mechanical Type Order code Pkg Weight
interlock unit qty (1 pce)
kg
AS09 … AS16, ASL09 … ASL16 with or without VM3 BER16C-3 1SBN081012R1000 1 0.035
Note: BER16C-3 connection set includes two BB3 fixing clips, and an electrical interlocking when fitted on contactors with built-in
N.C. auxiliary contacts. BER16C-3 can be used with or without VM3 mechanical interlock unit.
1SBC101070F0014 Connection sets for star-delta starting Type Order code Pkg Weight
Mech. interlock unit
For contactors
between Star & Delta
contactors qty (1 pce)
kg
AS09 … AS12, ASL09 … ASL12 with or without VM3 BEY16C-3 1SBN081018R2000 1 0.041 1SBC101297S0201
Note: BEY16C-3 connection set includes two BB3 fixing clips, and an electrical interlocking when fitted on Star and Delta contactors
BEY16C-3 with built-in N.C. auxiliary contacts. BEY16C-3 can be used with or without VM3 mechanical interlock unit.
ABB Motor protection and control - short form catalog | 4/13
