MS132 manual motor starters

0.10 to 32 A – with thermal and electromagnetic protection 02

MS132 is a compact and powerful range for motor protection up to 15 kW (400 V) / 32 A in width
of 45 mm. This type has also a clear and reliable indication of fault in a separate window in the
event of short-circuit tripping. Further features are the built-in disconnect function, temperature
compensation, trip-free mechanism and a rotary handle with a clear switch position indication.
The manual motor starter is suitable for three- and single-phase applications. The handle is
lockable to protect against unauthorized changes. Auxiliary contacts, signaling contacts,
undervoltage releases, shunt trips, power in-feed blocks are available as accessory.
2CDC241002V0013 Rated Setting range Short-circuit Rated Type Order code Weight
These are suitable throughout the MS116/MS132/MS165-range.
operational
breaking
(1 pce)
instantaneous
MS132-10 power capacity Ics short-circuit
400 V at 400 V AC current
AC-3, AC-3e setting li
kW A kA A kg
0.03 (1) 0.10 … 0.16 100 2.00 MS132-0.16 1SAM350000R1001 0.215
0.06 0.16 … 0.25 100 3.10 MS132-0.25 1SAM350000R1002 0.215
0.09 0.25 … 0.40 100 5.00 MS132-0.4 1SAM350000R1003 0.215
0.18 0.40 … 0.63 100 7.90 MS132-0.63 1SAM350000R1004 0.215
0.25 0.63 … 1.00 100 12.5 MS132-1.0 1SAM350000R1005 0.215
0.55 1.00 … 1.60 100 20.0 MS132-1.6 1SAM350000R1006 0.265
2CDC241006V0017 0.75 1.60 … 2.50 100 31.3 MS132-2.5 1SAM350000R1007 0.265
MS132-4.0
1SAM350000R1008
50.0
2.50 … 4.00
100
1.50
0.265
100
MS132-6.3
78.8
2.20
1SAM350000R1009
0.265
4.00 … 6.30
MS132-32 4.00 6.30 … 10.0 100 150 MS132-10 1SAM350000R1010 0.265
0.310
8.00 … 12.0
1SAM350000R1012
100
MS132-12
5.50
180
7.50 10.0 … 16.0 100 240 MS132-16 1SAM350000R1011 0.310
7.50 16.0 … 20.0 100 300 MS132-20 1SAM350000R1013 0.310
11.0 20.0 … 25.0 50 375 MS132-25 1SAM350000R1014 0.310
15.0 25.0 … 32.0 25 480 MS132-32 1SAM350000R1015 0.310
Mounted Auxiliary Contacts 1 N.O. + 1 N.C.
0.03 (1) 0.10 ... 0.16 100 2.00 MS132-0.16-HKF1-11 1SAM350005R1001 0.231
0.16 ... 0.25
100
3.10
1SAM350005R1002
MS132-0.25-HKF1-11
0.231
0.06
2CDC241021V0017 0.09 0.25 ... 0.40 100 5.0 MS132-0.4-HKF1-11 1SAM350005R1003 0.231
0.18
7.90
100
MS132-0.63-HKF1-11
0.40 ... 0.63
0.231
1SAM350005R1004
0.25
100
20.0
0.55 0.63 ... 1.00 100 12.5 MS132-1.0-HKF1-11 1SAM350005R1005 0.231
0.281
1.00 ... 1.60
1SAM350005R1006
MS132-1.6-HKF1-11
MS132-0.16-HKF1-11 0.75 1.60 ... 2.50 100 31.3 MS132-2.5-HKF1-11 1SAM350005R1007 0.281
1.50 2.50 ... 4.00 100 50.0 MS132-4.0-HKF1-11 1SAM350005R1008 0.281
2.20 4.00 ... 6.30 100 78.8 MS132-6.3-HKF1-11 1SAM350005R1009 0.281
4.00 6.30 ... 10.0 100 150 MS132-10.0-HKF1-11 1SAM350005R1010 0.281
5.50 8.00 ... 12.0 100 180 MS132-12.0-HKF1-11 1SAM350005R1012 0.326
7.50 10.0 ... 16.0 100 240 MS132-16.0-HKF1-11 1SAM350005R1011 0.326
7.50 16.0 ... 20.0 100 300 MS132-20-HKF1-11 1SAM350005R1013 0.326
11.0 20.0 ... 25.0 50 375 MS132-25-HKF1-11 1SAM350005R1014 0.326
MS132-32-HKF1-11
15.0
0.326
1SAM350005R1015
25.0 ... 32.0
25
480
2CDC241022V0017 Mounted Auxiliary Contacts 2 N.O. + 0 N.C. MS132-16-HKF1-20 1SAM350006R1011 0.326
7.50
10 ... 16
100
240
Note: Manual motor starters should always be selected so that the actual motor current is within the setting range.
MS132-32-HKF1-11 (1) 690 V
81.05 3.19"
72.2 2.84"
81.25 3.2"
72.4 2.85" 1.5 0.06" 5.5 0.22" 43.3 0.22"
1.5 0.06" 5.5 0.22" 43.5 1.71"
0.1"
0.1" 3.85" 1.7 2.95" 1.77"
3.54" 1.7 2.95" 1.38" 1.77" 97.8 75 1.38" 35 45
90 75 35 45"
2CDC131062C0201 - Rev. B
14 0.55" 14 0.55" 14 0.55" 14 0.55"
45 1.77" 45 1.77"
MS132 ≤ 10 A MS132 ≥ 12 A
Main dimensions mm, inches
