ABB MOTOR PROTECTION AND CONTROL 3/435

—

Voltage code table

03

NF contactor relays

Type Order code
NF 22 E - 13 1SBH137001R 13 22
AC coil code DC coil code
50/60 Hz
N.O. N.C. 41 24...60 V -
Number contacts 11 24...60 V 20...60 V
12 48...130 V 48...130 V
13 100...250 V 100...250 V
Contactor type 14 250...500 V 250...500 V
NF AC / DC operated

NF contactor relays with overlapping of lagging / leading contacts

N.O. leading contacts
N.C. lagging
Type contacts Order code
NF 33 / 11 - 13 1SBH137001R 13 39
AC coil code DC coil code
50/60 Hz
N.O. N.C. 41 24...60 V -
Number contacts 11 24...60 V 20...60 V
12 48...130 V 48...130 V
13 100...250 V 100...250 V
Contactor type 14 250...500 V 250...500 V
NF AC / DC operated

NF contactor relays - low consumption

Low coil consumption
Type Order code
NF Z 22 E - 21 1SBH136001R 21 22
AC coil code DC coil code
50/60 Hz
N.O. N.C. 20 - 12...20 V
Number contacts 21 24...60 V 20...60 V
22 48...130 V 48...130 V
23 100...250 V 100...250 V
NF Contactor type
AC / DC operated

NF contactor relays with overlapping of lagging / leading contacts - low consumption

Low coil consumption
N.O. leading contacts
Type N.C. lagging contacts Order code
NF Z 33 / 11 - 21 1SBH136001R 21 39
AC coil code DC coil code
50/60 Hz
N.O. N.C. 20 - 12...20 V
Number contacts 21 24...60 V 20...60 V
22 48...130 V 48...130 V
23 100...250 V 100...250 V
Contactor type 1SBC101601S0201 - Rev. E
NF AC / DC operated
