11/4             ABB  MOTOR PROTECTION AND CONTROL

          —

          The functions in detail

          Universal Motor Controller UMC100.3

















          Motor protection                  Motor control                      Control stations and operation modes
          •  The UMC provides comprehensive   •  Integration of the most important   •  Individual and flexible configuration
           motor protection                   motor control functions as ready,   •  Remote operation via DCS or PLC
          •  Overload protection for single and   easily parameterizable blocks  •  Local control via pushbuttons
           three-phase AC motors according to   •  Direct, reversing, star-delta starters  •  Local control via operatings panel
           EN/IEC 60947-4-1                 •  Pole changing/Dahlander           UMC100-PAN
          •  Rated motor currents from 0.24 to    Actuator mode                •  Force local via input signal
           63 A with an integrated measuring    •  Inching/jog mode
           system in a single version       •  Adjustable restart strategy (load   Motor status/communication
          •  Rated motor currents up to 850 A   shedding)                      Quick and comprehensive access to all
           with external current transformer                                   data via control station, fieldbus, Eth-
           CT4L/CT5L                        Extended motor control             ernet and/or laptop
          •  Selectable tripping classes 5E, 10E,   •  Freely programmable for special,
           20E, 30E or 40E                    application-specific control     Operating data
          •  Locked rotor protection          functions                        •  Motor status
          •  Phase failure, asymmetry and    •  Simple adaptation to specified   •  Motor current
           sequence protection                control functions                •  Thermal load
          •  Under-/ overcurrent protection  •  Comprehensive library          •  Maximum starting current
          •  Thermistor motor protection    •  Blocks for logic, counters, timing  •  Run-up time
          •  Ground leakage detection – internally   •  Access to all I/Os and internal    •  Time to trip
           or using CEM11-FBP.xxx sensors     signals                          •  Remaining cool-down time
          •  Limitation of motor starts per time
          •  Motor protection independent from                                 Operating data with voltage module
           bus communication                                                   VI150/VI155-FBP.0
                                                                               •  Phase voltages
          In combination with voltage module                                   •  Active power
          VI150/VI155-FBP.0                                                    •  Apparent power
          •  Undervoltage/overvoltage       Service data                       •  Power factor
           protection                       •  Counter for motor operating and   •  Energy
          •  Power supervision                standstill hours
   11
          •  Power factor supervision (cos j)  •  Number of starts
          •  Voltage-based detection of phase   •  Number of overload trips
           failure, asymmetry and sequence  •  Energy

                                            Diagnostic data
                                            •  Comprehensive and detailed error
                                              messages and warnings
                                            •  Log for previous 16 errors
                                            •  Plain text display on the control panel

                                            Open communication
                                            The UMC is a basic device that can use
                                            various communication methods; the
                                            communication protocol is selected by
                                            plugging-on the right fieldbus commu-
                                            nication interface or connecting an
                                            Ethernet communication interface.
