R contactors
Technical data

General technical data IOR, LOR, NOR contactors
IEC 60947-1 / 60947-4-1 and EN 60947-1 / 60947-4-1
Contactor types
Standards 1000 V AC or 1000 V DC (1500 V DC with increased insulation)
Rated insulation voltage Ui 1000 V AC or 1500 V DC
acc. to IEC 60947-4-1 and EN 60947-4-1 8 kV

R63 ... R500 -20...+70 °C
R800 ... R5100 -20...+80 °C
Rated impulse withstand voltage Uimp. Standard version for industrial environment and atmospheres
Ambient air temperature close to contactor 2000 m
Operation
Storage
Climatic withstand
Maximum operating altitude (without derating)

Mounting characteristics and condition for use

Contactor types IOR, LOR, NOR contactors

6 Mounting positions Position 1 (horizontal bar)

Mounting distances Maximum angle of inclination, in any direction : ±22° 30'
See "Dimensions"
