Spare parts R contactors
Main poles

Contact sets for N.O. or N.C. main poles1SBC388134F0302NB

Description

The contact sets include 1 fixed contact, 1 moving contact, 1 arcing horn (according to table below) and

2 screws.

The quantities needed are defined per ratings as follow:
–– 1 set per pole for R63….R800, R1000, R1400, R1700, R2100
–– 2 sets per pole for R1250, R1500, R2500, R3200, R3800
–– 3 sets per pole for R2000, R4500, R5100
–– 4 sets per pole for R3150
–– 5 sets per pole for R4000.

Ordering details Order code Pkg Weight
qty (1 pce)
For R contactors type FPTN410389R0001
FPTN410389R0002 kg
Contact set with arcing horn FPTN410389R0003
FPTN410389R0004 1 set 0.050
IOR, NOR, JOR, FOR 63, 85 FPTN410389R0005 1 set 0.150
1 set 0.250
125, 170 FPTN410390R0001 1 set 0.400
FPTN410390R0002 1 set 0.480
200, 260 FPTN410390R0003
FPTN410390R0004 1 set 0.040
315, 400 (1), 420 FPTN410390R0005 1 set 0.090
FPTN410391R0001 1 set 0.180
400 (2), 500, 550, 630 FPTN410503R0001 1 set 0.250
FPTN410506R0001 1 set 0.470
Contact set without arcing horn 1 set 0.520
1 set 0.520
LOR 85 1 set 0.830

170

260

420

400, 550

IOR, NOR, JOR, FOR, LOR 800, 1000, 1250, 1500, 2000, 3150, 4000

1400, 2500

1700, 2100, 3800, 4500, 5100

(1) For NOR and JOR types, N.C. poles
(2) For IOR, NOR, JOR types, N.O. poles

Arcing horns for N.O or N.C. main poles

Ordering details

For R contactors type Order code Pkg Weight
IOR, NOR, JOR, FOR qty (1 pce)
1SBC104033F0014
800, 1000, 1250, 1500, 2000, 3150, 4000 FPTN410446R0001 kg
1400, 2500 FPTN410446R0001
1700, 2100, 3200, 3800, 4500, 5100 FPTN410508R0001 1 0.200

1 0.200

1 0.280
