Spare parts R contactors
Auxiliary contacts

                         1SBC373832F0301  Auxiliary contact blocks type CA12                                                                     2

 CA12                                     Description
                                          CA12 auxiliary contact blocks 2 or 4-pole are mounted on a support bracket, above the electro-magnet.
CA15-F
CA15-O                                    The R contactors type R and RE can be equipped with:
                                          –– 1 or 2 x 2-pole blocks
                                          –– 1 x 2-pole block + 1 x 4-pole blocks.

                                          The R contactors type RR can be equipped with 1 or 2 x 2-pole blocks.

                                          Ordering details                        Auxiliary Type    Order code         Pkg Weight
                                                                                  contacts                             qty (1 pce)
                                          For R contactors type
                                          R, RE, RR                               11  CA12-1        FPTN410004R0001            kg
                                          (RC excluded)                           20  CA12-2        FPTN410005R0001
                                                                                  22  CA12-11       FPTN410013R0001    1 0.050
                                          Auxiliary contact blocks                13  CA12-12       FPTN410016R0001    1 0.050
                                          63...550                                40  CA12-22       FPTN410012R0001    1 0.090
                                                                                                                       1 0.090
                                          Support bracket                             Support bracket FPTN410056R0001  1 0.090
                                          63 …260                                     Support bracket FPTN410056R0002
                                          315 … 550                                                                    1 0.060
                                                                                                                       1 0.060

                                          Auxiliary contacts type CA15

                                          Description
                                          CA15 auxiliary contacts are mounted on a mounting kit, on the frame.

                                          Ordering details                        Auxiliary Type    Order code         Pkg Weight
                                                                                  contacts                             qty (1 pce)
        1SBC104054F0014                   For R contactors type
                                          R, RE, RR, RC                                                                        kg

                                          Auxiliary contact with screw terminals                                       1 0.070
                                                                                                                       1 0.070
                                          63 ... 5100                             10  CA15-F        FPTN410008R0004
                                                                                      CA15-O        FPTN410007R0006    1 0.070
                                                                                  01                                   1 0.070
                                                                                      CA15-F        FPTN210382R0003
                                          Auxiliary contact for railway           10  CA15-O        FPTN210382R0004    1 On
                                          63 ... 5100                             01                                           request
                                                                                      Universal     FPTN410054R0016
        1SBC104053F0014                   Mounting kit                                mounting kit                     1
                                          63 …170, 315...550,                         Mounting kit  FPTN410054R0017    1
                                          auxiliary frame ≥ 800                       Mounting kit  FPTN410213R0006
                                          200 … 260
                                          Main frame ≥ 800

                                          Special auxiliary contact blocks

                                          Please contact your local sales organization (order code of R contactor needed).
