Compact range
Non-illuminated selector switches - 3-position

—
Description
1SFC151255V0001 Compact selector switches operators are delivered in black color. Pkg Weight

Operating principle
Type
Contacts
Bezel
Order code
C3SS1-10B-11 qty (1 pce)
kg
03
Short handle
1SFC151359V0001 Black 1 1 C3SS1-10B-11 1SFA619210R1076 10 0.024
plastic
1SFA619210R1026
10
0.024
C3SS1-10B-20
2 0
Chrome
metal 1 1 C3SS1-30B-11 1SFA619210R3076 10 0.032
C3SS1-30B-20
2 0
1SFA619210R3026
0.032
10
C3SS2-30B-20
Black 1 1 C3SS2-10B-11 1SFA619211R1076 10 0.024
plastic 2 0 C3SS2-10B-20 1SFA619211R1026 10 0.024
Chrome 1 1 C3SS2-30B-11 1SFA619211R3076 10 0.032
metal 2 0 C3SS2-30B-20 1SFA619211R3026 10 0.032
Black 1 1 C3SS3-10B-11 1SFA619212R1076 10 0.024
plastic 2 0 C3SS3-10B-20 1SFA619212R1026 10 0.024
Chrome 1 1 C3SS3-30B-11 1SFA619212R3076 10 0.032
metal 2 0 C3SS3-30B-20 1SFA619212R3026 10 0.032
Black 1 1 C3SS7-10B-11 1SFA619216R1076 10 0.024
plastic 2 0 C3SS7-10B-20 1SFA619216R1026 10 0.024
Chrome 2 0 C3SS7-30B-20 1SFA619216R3026 10 0.032
metal
Long handle
Black 1 1 C3SS4-10B-11 1SFA619213R1076 10 0.024
Contacts actuated plastic 2 0 C3SS4-10B-20 1SFA619213R1026 10 0.024
3-position selector switch
Contacts included, Black 1 1 C3SS5-10B-11 1SFA619214R1076 10 0.024
actuated in position: plastic 2 0 C3SS5-10B-20 1SFA619214R1026 10 0.024
A C
NC NO NC NO Chrome 1 1 C3SS5-30B-11 1SFA619214R3076 10 0.032
21 23 11 13 metal 2 0 C3SS5-30B-20 1SFA619214R3026 10 0.032
Black 2 0 C3SS6-10B-20 1SFA619215R1026 10 0.024
plastic
22 24 12 14
2 NO – 1 – 1 Black 2 0 C3SS8-10B-20 1SFA619217R1026 10 0.024
2 NC 1 – 1 –
1 NO + 1 NC 1 – – 1 plastic

1.5 0.06" - 6 0.24"
1.5 0.06" - 6 0.24"

Ø 30 1.18" Ø 20 0.79" Ø 29 1.14" Ø 30 1.18" Ø 20 0.79"
25.5 1.00"

42 1.65" 30 1.18" 42 1.65" 30 1.18"
C3SS, short handle C3SS, long handle 1SFC151047S0201
Dimensions (mm, inches)
