RCCV wire and cable markers
Slide-in blank label

1SNC700227F0000 Description

RCCV –– Blank marker card for wire and cable identification,
–– Markers are protected in the marker holders,
–– To be slided in PETC transparent holder,
–– Made of halogen-free PVC.

Main technical data Flammability Temperature range
V0 -20°C to +60°C -4°F to +140°F
Material
PVC

Ordering details

Dimensions Maximum Nb. of Color Type Order code Pkg Weight 4
mm in printed digits markers RCCV 1SNA235460R0400 pce (1 pce) g
Hor. Vert. per card

Card of 48 blank markers compatible with PETC holders

4.2 x 16.5 0.165 x 0.650 48 White 1 10.00

Marking system accessories SPRCC 2 1SNA360011R0200 1 330.00

SPRCC 2
Support plate for AMS500
Purchased separately

Mounting instruction

PETC transparent marker holders
For RCCV makers

Description

–– Transparent marker holder for wire and cable identification,
–– To be used with RCCV markers,
–– Made of PVC.
1SNC160251F0014
1SNC160134S0201Main technical dataFlammabilityTemperature range
-20°C to +90°C -4°F to +194°F
Material
PVC

Ordering details

Wire ext. diameter Wire Holder length Color Type Order code Pkg Weight
section
mm in mm² mm in Transparent PETC 51 1SNA168737R0200 pce (1 pce) g
18 0.709 Transparent PETC 53 1SNA168741R1600 100
1.1 ... 3.3 0.043 ... 0.130 0.1 ... 1 Transparent PETC 56 1SNA168747R1400 100
1.5 ... 4.5 0.059 ... 0.177 1 ... 2.5 100
3 ... 8 0.118 ... 0.315 2.5 ... 10

All the technical data for UL/CSA standard and dimensions in inches are in italic.

ABB Solution series - Markers and marking systems | 103
