Page 104 - 1SNC160023C0204_Marking_systems_catalog_EN

PCGS wire and cable markers
Slide-in precut blank labels

1SNC700181F0000 Description

–– Blank marker card for thick wires,
–– To be inserted in RINGT209 holder,
–– Made of PVC.

PCGS209 Main technical data Flammability Temperature range
V0 -40°C to +60°C -40°F to +140°F
4 Material
PVC

Ordering details Nb. of Color Type Order code Pkg Weight
markers PCGS209 card (1 card) g
Dimensions per card

mm in

PCGS 60 White 1SNA235150R0500 40 10.00

For RINGT holders
20 x 9.3 0.787 x 0.366

Marking system accessories

SPRC 21 SPRC 21 1SNA360031R0600 1 500.00

Support plate for AMS500 and AMS250
Purchased separately

Use holders only with designated cable marker of the same or a shorter length.

RINGT209 transparent marker holders
For PCGS markers

1SNC160100F0014 Description

–– Transparent tie-on marker holders profiled to allow thick tube identification,
–– Use with PCGS209 markers,
–– Made of PVC.

RINGT209 Main technical data Flammability Temperature range
V0 -50°C to +80°C -58°F to +176°F
Material
PVC

Ordering details Color Type Order code Pkg Weight
1SNA235142R2100 pce (1 pce) g
Dimensions
240 6.00
mm in

For thick tube mounting

RINGT209

Tie-on sealed transparent holder for PCGS markers

9.5 x 20 0.374 x 0.787 Transparent RINGT209

Use holders only with designated cable marker of the same or a shorter length.
Dimensions given apply to the labelling area.

1SNC160121S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
102 | ABB Solution series - Markers and marking systems
