PEB end stop label holders
For RCPEB, PIB, PIB3 labels

Description

–– To be used for terminal block assembly identification,
–– Direct insertion onto end stops from SNA series,
–– Compatible with RCPEB, PIB, PIB3 labels.

1SNC160200F0014 Main technical data

Material Flammability Temperature range

Polyamide (PEB) V0 -55°C to +110°C -67°F to +230°F
PVC (EPR1)
PEB

Ordering details Color Type Order code 4Pkg Weight

Dimensions

mm in pce (1 pce) g
50 1.70
PEB 1 0.054
50 2.80
Label holder for end stop 35 x 17 mm 1.378 x .669 in, to be snapped onto end stop

18 x 35.5 0.709 x 1.378 Grey PEB 1SNA113077R1100

EPR1

Card of 54 PVC protective covers

17.5 x 35 0.689 x 1.378 Transparent EPR1 1SNA178431R2200

PEBM 1SNA113084R0100

"All in one": PEB marker holder with marker and protection included
PEBM

Compatible end stops

BAM2 BADL BADH BAMH BAR BADRL 1SNC160125S0201 - Rev. A

1SNA206351R1600 1SNA399903R0200 1SNA116900R2700 1SNA114836R0000 1SNA164519R2400 1SNA199420R2100

All the technical data for UL/CSA standard and dimensions in inches are in italic.
