MCLH end stop markers
Self-adhesive precut blank labels for SNK series
1SNC700301F0000 Description
–– Identify your terminal blocks assembly with the self-adhesive label adapted to the LH label holders.
MCLH, MCLH-R1 Main technical data Flammability Temperature range
V0 -55°C to +110°C -67°F to +230°F
4 Material
PVC + Adhesive acrylic
Ordering details Nb. of Color Type Order code Pkg Weight
markers card (1 card) g
Dimensions per card White MCLH 1SNK900630R0000
Yellow MCLH-YL 1SNK900633R0000 25 10.00
mm in 25 10.00
White MCLH-R1 1SNK900631R0000
For LH label holder Yellow MCLH-R1-YL 1SNK900634R0000 25 10.00
25 10.00
MCLH 1.181 x 0.346 36
30 x 8.8
For LH-R1 label holder
MCLH-R1
35.35 x 1.392 x 0.695 15
17.65
Marking system accessories SPRC 21 1SNA360031R0600 1 500.00
SPRC 21
Support plate for AMS500 and AMS250
Purchased separately
Mounting instruction 8.8
MCLH 0.346"
30 1.18" 17.65 0.695"
MCLH-R1
35.35 1.39"
Compatible holders
LH LH-R1 1SNC160128S0201
All the technical data for UL/CSA standard and dimensions in inches are in italic.
