RPEV terminal block markers
Precut blank labels for SNA and Solution series

1SNC700163F0000 Description
–– Precut PVC label,
–– To be used with PEV pivoting marker holder.

RPEV Main technical data

Material Flammability
PVC

Ordering details Nb. of Color Type Order code Pkg Weight
markers RPEV 1SNA173178R0700 card (1 card) g
Dimensions per card 4

mm in

RPEV 0.236 x 1.142 99 White 1 9.20
6 x 29

Marking system accessories SPRC 21 1SNA360031R0600 1 500.00

SPRC 21
Support plate for AMS500 and AMS250
Purchased separately

PEV pivoting terminal block marker holders
For RPEV markers

Description

–– To be slided into 6 mm 0.236 in spacing terminal blocks,
–– Can be placed side by side from 10 mm 0.394 in spacing,
–– The pivoting upper part provides access to the compression screws,
–– Designed to be mounted individually.

Main technical data

Material
1SNC160192F0014 Flammability
6 0.24"
PEV Ordering details 6 0.24"
8 0.31"
1SNC160119S0201DimensionsNb. ofColorTypeOrder codePkg Weight
mm in markers pce (1 pce) g
per card

PEV

Pivoting marker holder

6 x 29 0.236 x 1.142 Grey PEV 1SNA113180R1200 10 1.00

Dimensions given apply to the labelling area.

Mounting instruction (2) 1 - For 6 mm (0.236 in) and
8 mm (0.315 in) spacing
(1) terminal blocks : PEV can be
used on every other block
29 1.14" 2 - From 10 mm (0.394 in)
spacing terminal blocks : PEV
can be used side by side

All the technical data for UL/CSA standard and dimensions in inches are in italic.
