RCPEAD end stop labels
Precut blank labels

1SNC700232F0000 Description
–– Identify your terminal block assemblies with the self-adhesive label adapted to the PEAD label holders.

Main technical data Flammability

RCPEAD Material
PVC
4
Ordering details Nb. of Color Type Order code Pkg Weight
markers RCPEAD 1SNA399725R0600 card (1 card) g
Dimensions per card
1 5.00
mm in

RCPEAD

9 x 29 0.354 x 1.142 40 White

Marking system accessories SPRC 21 1SNA360031R0600 1 500.00

SPRC 21
Support plate for AMS500 and AMS250
Purchased separately

Mounting instruction

PEAD + RCPEAD

PEAD end stop label holders
For RCPEAD label

Description

–– Easily identify your terminal block assemblies with white or yellow labels,
–– Adjustable in height for best visibility,
–– Compatible with BAM2 and BADL SNA series end stops.

1SNC160058F0014 Main technical data Flammability
V0
Material
Polyamide

Ordering details

PEAD Dimensions Color Type Order code Pkg Weight
mm 1SNA399719R1000 pce (1 pce) g
in 1SNA399726R0700
20 0.78
PEAD
1 4.00
Label holder for end stop, compatible with RCPEAD marker and EPR2 cover.

9 x 29 0.354 x 1.142 Grey PEAD

EPR2

Card of 20 covers for RCPEAD and RCPEAD-TT markers

9 x 29 0.354 x 1.142 Transparent EPR2

Dimensions given apply to the labelling area.

Compatible end stops

BAM2 BADL 1SNC160122S0201 - Rev. A
1SNA206351R1600 1SNA399903R0200

All the technical data for UL/CSA standard and dimensions in inches are in italic.
