RING, SNAP transparent marker holders
For WM markers

1SNC160251F0014 Description

–– Transparent marker holder profiled to allow marking on various cable sizes, up to ø 10 mm 0.394 in,
–– Use with WM and WMTT markers,
–– Made of PVC.

Main technical data Flammability Temperature range
V0 -50°C to +80°C -58°F to +176°F
Material
PVC

Ordering details Wire Holder length Color Type Order code Pkg Weight 4
section mm in pce (1 pce) g
Wire ext. diameter mm² 1SNA235117R1000
1SNA235118R2100
mm in 1SNA235119R2200
1SNA235120R2700
For cable mounting
1SNA235123R1600
RING 1SNA235124R1700
1SNA235125R1000
12 mm 0.472 in sealed transparent holder for WM12 and WMTT12 markers 1SNA235126R1100

1.5 ... 2.5 0.059 ... 0.098 12 0.472 Transparent RING122 1SNA235129R2400 3000 1.80
1SNA235130R2100 3000 2.20
RING 2 ... 4 0.079 ... 0.157 Transparent RING124 1SNA235131R1600 2000 0.30
SNAP 1SNA235132R1700 2000 0.50
RINGT23 4 ... 7 0.157 ... 0.276 Transparent RING127
1SNA235133R1000 3000 0.30
6 ... 10 0.236 ... 0.394 Transparent RING1210 1SNA235134R1100 3000 0.30
1SNA235135R1200 2000 0.50
18 mm 0.709 in sealed transparent holder for WM18 and WMTT18 markers 1SNA235136R1300 1000 0.70

1.5 ... 2.5 0.059 ... 0.098 18 0.709 Transparent RING182 1SNA235137R1400 1000 0.40
1000 0.40
2 ... 4 0.079 ... 0.157 Transparent RING184 500 0.50
500 1.40
4 ... 7 0.157 ... 0.276 Transparent RING187
500 0.40
6 ... 10 0.236 ... 0.394 Transparent RING1810 500 0.60
200 0.90
SNAP 200 2.20

12 mm 0.472 in un-sealed transparent holder for WM12 and WMTT12 markers

2 ... 3.5 0.079 ... 0.138 15 0.591 Transparent SNAP152

2.8 ... 5 0.110 ... 0.197 Transparent SNAP154

5 ... 8 0.197 ... 0.315 Transparent SNAP157

8 ... 10 0.315 ... 0.394 Transparent SNAP1510

23 mm 0.906 in in un-sealed transparent holder for WM18 and WMTT18 markers

2 ... 3.5 0.079 ... 0.138 23 0.906 Transparent SNAP232

2.8 ... 5 0.110 ... 0.197 Transparent SNAP234

5 ... 8 0.197 ... 0.315 Transparent SNAP237

8 ... 10 0.315 ... 0.394 Transparent SNAP2310

For thick tube mounting

RINGT23

23 mm 0.906 in tie-on sealed transparent holder for WM and WMTT markers

23 0.906 Transparent RINGT23 200 0.40

Use holders only with designated cable marker of the same or a shorter length.

1SNC160137S0201

All the technical data for UL/CSA standard and dimensions in inches are in italic.
