CP-T range
Ordering details

Description 3

2CDC 271 043 S0009 The CP-T range of three-phase power supply units is the youngest member of ABB‘s power
supply family. In terms of design and functionality, the new range perfectly supplements the ex-
isting products and extends the range appropriately. The devices can be supplied with a three-
phase voltage as well as with two-phase mains. Here, ABB offers power supply units with 24 V
DC and 48 V DC outputs with 5 A, 10 A, 20 A and 40 A and efficiency of up to 92 %. As in the
case of all products, they are designed for an ambient temperature of up to 70 °C. All prod-
ucts can be supplied within an AC supply voltage range between 340 to 575 V AC and a DC
supply voltage range between 480 to 820 V DC.

Ordering details Rated Type Order code Price Weight
output voltage / 1 pce (1 pce)
CP-T 24/5.0 Input voltage range current 1SVR427054R0000 kg (lb)
CP-T 24/10.0, CP-T 48/5.0 1SVR427055R0000
340-575 V AC / 480-820 V DC 24 V DC / 5 A CP-T 24/5.0 1SVR427056R0000 0.80
340-575 V AC / 480-820 V DC 1SVR427057R0000 (1.77)
340-575 V AC / 480-820 V DC 24 V DC / 10 A CP-T 24/10.0 1SVR427054R2000
340-575 V AC / 480-820 V DC 1SVR427055R2000 1.05
340-575 V AC / 480-820 V DC 24 V DC / 20 A CP-T 24/20.0 1SVR427056R2000 (2.31)
340-575 V AC / 480-820 V DC
2CDC 271 045 S0009 340-575 V AC / 480-820 V DC 24 V DC / 40 A CP-T 24/40.0 1.75
(3.86)
48 V DC / 5 A CP-T 48/5.0
3.20
(7.05)

1.05
(2.31)

48 V DC / 10 A CP-T 48/10.0 1.75
(3.86)

48 V DC / 20 A CP-T 48/20.0 3.40
(7.50)

2CDC 271 047 S0009

CP-T 24/20.0, CP-T 48/10.0

2CDC 110 004 C0210 | Catalog Electronic Products and Relays 2015 | ABB 3/34
