CP-T range
Technical data

Data at Ta = 25 °C, Uin = 3 x 400 V AC and rated values, unless otherwise indicated

Type CP-T 48/5.0 CP-T 48/10.0 CP-T 48/20.0
General data
Efficiency typ. 91 % typ. 93 %
Duty time
Dimensions (W x H x D) 100% 150 x 124 x 118.8 mm 275.8 x 124 x 118.8 mm
(5.91 x 4.88 x 4.68 in) (10.86 x 4.88 x 4.68 in)
89 x 124 x 118.8 mm
(3.5 x 4.88 x 4.68 in)

Weight 1.045 kg (2.30 lb) 1.657 kg (3.653 lb) 3.275 kg (7.22 lb)
Material of housing
Mounting Metal 3
Mounting position
Minimum distance to other units DIN rail (IEC EN 60715), snap-on mounting without any tool
Degree of protection
Protection class horizontal

horizontal / vertical 25 mm / 25 mm (0.98 in / 0.98 in)

housing / terminals IP20 / IP20

I

Electrical connection - input circuit / output circuit

Wire size fine-strand with wire end ferrule 0.2-4 mm² (24-11 AWG) 0.2-4 mm² (24-11
AWG) / 0.5-10 mm²
(20-8 AWG)

fine-strand without wire end ferrule 0.2-6 mm² (24-10 AWG)

rigid

Stripping length 8 mm (0.31 in)

Tightening torque input / output 1 Nm (9 lb.in) / 0.6 Nm (5.5 lb.in) 1 Nm (9 lb.in) /
1.8 Nm (15.6 lb.in)
Environmental data operation -40…+70 °C -30…+70 °C
Ambient temperature range -40…+70 °C

rated load -40…+60 °C -30…+60 °C -40…+60 °C

storage -40…+85 °C -40…+85 °C -40…+85 °C

Damp heat (cyclic) (IEC/EN 60068-2-30) 95 % without condensation

Vibration (sinusoidal) (IEC/EN 60068-2-6) 10-500 Hz, 2G, each along X, Y, Z axes 6 min / cycle

Shock (half-sine) (IEC/EN 60068-2-27) 15G, 11 ms, 3 axes, 6 Faces, 3 times for each face

Isolation data input circuit / output circuit 3 kV AC
Rated insulation voltage Ui input / PE 1.5 kV AC

Pollution degree output / PE 0.5 kV AC; 0.71 kV DC
Standards 2
Product standard
Low Voltage Directive EN 61204-3
EMC directive 2006/95/EC
RoHS directive 2004/108/EC
Electrical safety 2011/65/EC
EN 60950-1, UL 60950-1, UL 508, EN 61558-1, EN 61558-2-16;
Protective low voltage EN 60204-1
Electromagnetic compatibility SELV
Interference immunity to
electrostatic discharge IEC/EN 61000-6-2
radiated, radio-frequency, electromagnetic IEC/EN 61000-4-2 Level 4 (air discharge 15 kV / contact discharge 8 kV)
field IEC/EN 61000-4-3 Level 3 (10 V/m)
electrical fast transient/burst
surge IEC/EN 61000-4-4 Level 4 (4 kV / 5 kHz)
conducted disturbances, induced by radio- IEC/EN 61000-4-5 L-L Level 3 (2 kV) / L-PE Level 4 (4 kV)
frequency fields IEC/EN 61000-4-6 Level 3 (10 V)
power frequency magnetic fields
voltage dips, short interruptions and voltage IEC/EN 61000-4-8 Level 4 (30 A/m)
variations IEC/EN 61000-4-11 dips: >95 % 0.5 ms / >30 % 0.5 ms
Interference emission
high-frequency radiated interruptions: >95 % 250 ms
high-frequency conducted IEC/EN 61000-6-3
limits for harmonic current IEC/CISPR 22, EN 55022 Class B
emissions IEC/CISPR 22, EN 55022 Class B
IEC/EN 61000-3-2 Class A

„Approvals and marks“ on page 3/4.
