CP-S and CP-C
Benefits and advantages

Characteristics Benefits
CP-S and CP-C range
– Output current 5 A, 10 A and 20 A Integrated power reserve 1
– Integrated power reserve of up to 50 % The new CP-S and CP-C range power supplies feature an in-
– 5 A and 10 A devices with pluggable connecting terminals tegrated power reserve of up to 50 %. No oversized electricity
– Approvals / marks supply is needed, especially under heavy load conditions.

(depending on device, partly pending) Pluggable connecting terminals 2
Extended flexibility in operation due to pluggable connecting
– A, H, R, K, / a, b terminals (this feature is not offered on all devices).
3
Adjustable output voltage 3
CP-S range
– 10 A and 20 A device with front-face selector switch to The CP-C range types feature a continuously adjustable

adjust rated input voltage range: output voltage from 22 to 28 V. Thus, they can be optimally
110-120 V AC or 220-240 V AC
– Output voltage fixed at 24 V DC adapted to the application, e.g. compensating the voltage
– Parallel operation for redundancy
drop caused by long line length.
CP-C range
– Wide range input 110-240 V AC (85-264 V AC, 100-350 V DC) Pluggable function modules 4
– Output voltage adjustable within a range of 22-28 V DC The CP-C range power supplies can be equipped with plug-
– Parallel operation for increased capacity and redundancy gable modules to add additional functions (e.g. messaging
– Power factor correction (PFC) acc. to EN 61000-3-2 module). Thus, the power supplies can be ideally adapted to
– Function module pluggable onto the front side the relevant application.

Messaging module CP-C MM:
– LED for status indication
– Relay outputs "Input OK" and "Output OK"
– REMOTE ON/OFF function to switch on and off the

power supply externally
– Output voltage monitoring is only possible in decoupled

parallel operation

2CDC 273 056 F0004
2CDC 273 057 F0004
2CDC 273 046 F0004
2CDC 273 058 F0004
12 3 4
