CP-T range
Technical data

Data at Ta = 25 °C, Uin = 3 x 400 V AC and rated values, unless otherwise indicated

Type CP-T 24/5.0 CP-T 24/10.0 CP-T 24/20.0 CP-T 24/40.0

General data typ. 89 % typ. 90 % typ. 92 %
Efficiency
Duty time 100% 89 x 124 x 118.8 150 x 124 x 275.8 x 124 x
Dimensions (W x H x D) mm 118.8 mm 118.8 mm
74.3 x 124 x (3.5 x 4.88 x (5.91 x 4.88 x (10.86 x 4.88 x
118.8 mm 4.68 in) 4.68 in) 4.68 in)
(2.92 x 4.88 x
4.68 in)

Weight 0.78 kg (1.72 lb) 1.045 kg (2.30 lb) 1.657 kg (3.653 lb) 3.275 kg (7.220 lb) 3
Material of housing Metal
Mounting DIN rail (IEC EN 60715), snap-on mounting without any tool
Mounting position horizontal
Minimum distance to other units horizontal / vertical 25 mm / 25 mm (0.98 in / 0.98 in)
Degree of protection housing / terminals IP20 / IP20
Protection class I

Electrical connection - input circuit / output circuit / signalling circuit

Wire size fine-strand with wire end ferrule 0.2-4 mm² (24-11 AWG)

fine-strand without wire end ferrule 0.2-6 mm² (24-10 AWG)

rigid 0.2-6 mm² (24-10 AWG)

Stripping length 8 mm (0.31 in) 1 Nm (9 lb.in) /
Tightening torque input / output 1 Nm (9 lb.in) / 0.6 Nm (5.5 lb.in) 1.8 Nm (15.6 lb.in)

Environmental data operation -40...+70 °C -30…+70 °C -40...+70 °C
Ambient temperature range

rated load -40...+60 °C -30…+60 °C -40...+60 °C

storage -40…+85 °C

Damp heat (cyclic) (IEC/EN 60068-2-30) 95 % without condensation

Vibration (sinusoidal) (IEC/EN 60068-2-6) 2 g, 10-500 Hz, 2G, each along X, Y, Z axes 60 min / cycle

Shock (half-sine) (IEC/EN 60068-2-27) 15 g, 11 ms, 3 axes, 6 faces, 3 times for each face

Isolation data input circuit / output circuit 3 kV AC
Rated insulation voltage Ui input / PE 1.5 kV AC

Pollution degree output / PE 0.5 kV AC; 0.71 kV DC
signalling output / PE 0.5 kV DC

2

Standards EN 61204-3
Product standard 2006/95/EC
Low Voltage Directive 2004/108/EC
EMC directive 2011/65/EC
RoHS directive EN 60950-1, UL 60950-1, UL 508, EN 61558-1, EN 61558-2-17; EN 60204-1
Electrical safety SELV
Protective low voltage

Electromagnetic compatibility IEC/EN 61000-6-2
Interference immunity to IEC/EN 61000-4-2 Level 4 (air discharge 15 kV / contact discharge 8 kV)
IEC/EN 61000-4-3 Level 3 (10 V/m)
electrostatic discharge
IEC/EN 61000-4-4 Level 4 Level 4 (4 kV / 5 kHz)
radiated, radio-frequency, electromagnetic
field
electrical fast transient/burst

(4 kV / 2.5 kHz)

surge IEC/EN 61000-4-5 L-L Level 3 (2 kV) / L-PE Level 4 (4 kV)
IEC/EN 61000-4-6 Level 3 (10 V)
conducted disturbances, induced by radio-
frequency fields IEC/EN 61000-4-8 Level 4 (30 A/m)
power frequency magnetic fields IEC/EN 61000-4-11 dips: >95 % 0.5 ms / >30 % 0.5 ms, interruptions: >95 % 250 ms

voltage dips, short interruptions and voltage
variations

Interference emission IEC/EN 61000-6-3
high-frequency radiated IEC/CISPR 22, EN 55022 Class B
high-frequency conducted IEC/CISPR 22, EN 55022 Class B
limits for harmonic current emissions
IEC/EN 61000-3-2 Class A

„Approvals and marks“ on page 3/4.
