Analog signal converters - CC-E range
Technical data

Type CC-E/STD / CC-E x/x CC-E/RTD 3) CC-E/TC
Input circuits - Analog inputs Thermocouples
J-G-H Current Voltage Temperature sensors

Input signal Standard signals PT100 (IEC 584-1 and 2)
Rated input range TC.K, TC.J

Limitation of input signals 0...20 mA / 0...5 V / -50...+500 °C TC.K: 0...1000 °C,
Influence of line resistance 4...20 mA 0...10 V / TC.J: 0...600 °C
Gain adjustment range
Offset adjustment range -10...+10 V < 0.5 % / 100 ⏲
Input impedance +55 mA ± 11 V
Suppression at 50 Hz - < 0.01 %/⏲
± 5 % (universal devices)
4 Common-mode rejection ± 5 % (universal devices)
Output circuits - Analog outputs
Output signal 50 ⏲ 1 M⏲ - -
Output burden
Accuracy 1) - - > 35 dB
Residual ripple
Response time - 100 dB
Transmission frequency
Reaction to input circuit interruption D-F, A-C Current Voltage
0-5 V, 0-10 V
Supply circuits 0-20 mA, 4-20 mA
Supply voltage
Supply voltage tolerance ͨ 500 ⏲ ͧ1.0 K⏲
Power consumption
Indication of operational states ± 0.5 % of full-scale
Rated control supply voltage US
General data < 0.5 %
Ambient temperature rangeoperation / storage
Temperature coefficient 200 μs 10 ms
Degree of protection (DIN 40050)
Mounting position 2 kHz 80 Hz 2 Hz (up to -3 dB)

K-M High fail safe: Output voltage > 115 % of
24 V DC
measuring range 2)

Low fail safe: Output voltage < -0.6 V, output

current = 0 mA

DC versions AC versions

110-240 V AC - 50/60 Hz

-15...+15 % -15...+10 %
1.5 W typ. 1.5 VA typ.

U: green LED

0...+60 °C / -20...+80 °C
± 500 ppm/°C
IP20
ventilation slots on top and bottom

Mounting DIN rail (IEC/EN 60715), snap-on mounting

Electrical connection

Wire size rigid 0.2-4 mm2 (24-12 AWG)

fine-strand with(out) wire end ferrule 0.2-2.5 mm2 (24-14 AWG)

Stripping length 7 mm (0.28 inch)

Tightening torque 0.5 Nm (4.4 lb.in)

Electromagnetic compatibility

Interference immunity EN 61000-6-2

electrostatic discharge (ESD) IEC/EN 61000-4-2 Level 3 (±6 kV / ±8 kV)

electromagnetic field(HF radiation IEC/EN 61000-4-3 10 V/m

resistance)

fast transients (Burst) IEC/EN 61000-4-4 Level 3 (±2 kV / 5 kH)

powerful impulses (Surge) IEC/EN 61000-4-5 ±2 kV / ±1 kV

HF line emission IEC/EN 61000-4-6 10 V

Interference emission EN 61000-6-4 Class B

Isolation data

Test voltage between all isolated circuits 2.5 kV AC

Rated insulation voltage -- -

1) Includes non-linearity and factory setting, influenced by supply voltage and output load.
2) Only -/RTD and -/TC: Single-function devices respond with Low fail safe to input signal interruptions.
3) When connecting a 2-wire sensor, the terminals J and H have to be jumpered.
Approvals see „Overview“ on page 4/3
