Analog signal converters - CC-U range
Overview

CC-U/STD universal signal converter with 3-way electrical CC-U/STDR universal signal converter for standard

isolation signals, with 2 threshold relay outputs and with 3-way

– More than 120 configurations possible electrical isolation
– Configurable output signal response on input voltage signal – Standard signal converter with 7 setting ranges
– 2 threshold relay outputs with one c/o contact each
interruption (low fail safe / high fail safe)
– Adjustment and operating elements on the front (threshold and respective hysteresis can be
– Short-circuit proof signal outputs adjusted independently from each other)
– Plug-in connecting terminals for inputs, outputs and supply – Open-circuit or closed-circuit principle configurable by
– Very fast signal transmission enables use in control sys- means of a DIP switch
– 2 yellow LEDs for clear status indication of the output
tems

relays

4 – Plug-in connecting terminals for inputs, outputs and supply

CC-U/RTD universal signal converter for PT10, PT100,
PT1000 temperature sensors (acc. to IEC 751 and JIS C
16041), linearized with 3-way electrical isolation)
– Configurable output signal response on input signal inter-

ruption (low / high fail safe)
– Adjustment and operating elements on the front-side
– Short-circuit proof signal outputs
– Plug-in connecting terminals for inputs, outputs and supply
– 2- or 3-wire connection

1) Japanese standard

CC-U/TC universal signal converter for thermocouples CC-U/TCR universal signal converter for thermocouples,

with 3-way electrical isolation with 2 threshold relay outputs and 3-way electrical
– Temperature signal converter for thermo-couples of the
isolation
types K, J, T, S, E, N, R, B – Temperature signal converter for thermocouples of the
– Continuously adjustable voltage signal input 0-10 mV and
types K, J, T, S
0-50 mV – 2 threshold relay outputs with one change-over contact
– Differential temperature meas. possible (see „Wiring
each (threshold and respective hysteresis can be adjusted
instructions“ on page 20) independently from each other)
– Configurable output signal response on input signal inter- – Open-circuit or closed-circuit principle configurable by
means of a DIP switch
ruption (low fail safe / high fail safe) – 2 yellow LEDs for clear status indication of the output
– Adjustment and operating elements on the front-side relays
– Short-circuit proof signal outputs – Plug-in connecting terminals for inputs, outputs and supply
– Plug-in connecting terminals for inputs, outputs and supply – Integrated cold-junction compensation
– Cold-junction compensation selectable

CC-U/V universal measuring converter for RMS values of CC-U/I universal measuring converter for RMS values of

0-600 V, with 3-way electrical isolation 0-1 A and 0-5 A, with 3-way electrical isolation
– RMS converter for voltage signals up to 600 V of any wave – RMS converter for current signals up to 1 A and up to 5 A

form (DC, DC with superimposed AC components, pure of any wave form (DC, DC with superimposed AC compo-
sinusoidal, triangular, phase-angle controlled, etc. in a nents, pure sinusoidal, triangular, phase-angle controlled,
measuring range of 0-600 Hz) etc. in a measuring range of 0-600 Hz)
– Adjustment and operating elements on the front – Adjustment and operating elements on the front
– Short-circuit proof signal outputs – Short-circuit proof signal outputs
– Plug-in connecting terminals for inputs, outputs and supply – Plug-in connecting terminals for inputs, outputs and supply
