Logic relays
System overview

Logic relays                                                                                                                                                                                           Display system Ǟ Compact HMI logic relay
      Stand alone
                                                                              Expandable                                                                                                                                CL-NET                          8
                                                                                                                                                                                                                            ...
                                                                                                                                                                                                                     4
                                                                                                                                                                                                       10 7 4

                                                                Power                                                                         Power                                                                        9

2                                                                             2

              1a                                                                 1b 7                                                                                                                  52               3                                                         2CDC 312 025 F0b06

           6, 8b                                                             6, 8b                                                                                                                                                                                             3
    5                                                                  5
   8a                                                                                                                                                                           3                                    12
 9                                                                                 8a                                                                                    4
                                                                                 9                                                                                                                                                                                          1
8b
                                                                               8b                                                                                                                      6

                                                                                                                                                                                                       1 Display module CL-LDD..                                                                      6
                                                                                                                                                                                                       2 Display base module CL-LDC.LN..
                                                                                                                                                                                   2CDC 312 001 F0b08  3 Display I/O module CL-LDR.., CL-LDT..
                                                                                                                                                                                                       4 Termination resistor CL-LAD.TK009
                                                                                                                                                                                                       5 I/O expansion CL-LER.., CL-LET..
                                                                                                                                                                                                       6 Coupler unit CL-LEC.. for remote expansion
                                                                                                                                                                                                       7 Memory module CL-LAD.MD004 for display base module
                                                                                                                                                                                                       8 Connecting cable CL-LAD.TK002, CL-LAD.TK003,

                                                                                                                                                                                                                  CL-LAD.TK004
                                                                                                                                                                                                       9 Connecting cable CL-LAD.TK001, CL-LAD.TK011

                                                                                                                                                                                                                  to connect PC
                                                                                                                                                                                                       10 CL-LINK plug CL-LAS.TK011

                                                                                                                                                                                                                  for expansion of logic relays CL-LM..
                                                                                                                                                                                                       ࡯ e.g. door of switchgear cabinet

1a Logic relay CL-LS..                                                                                                                                                                                 Stand alone with I/O module  2CDC 312 027 F0b06
1b Expandable logic relay CL-LM..
2 Power supply CP-D...                                                                                                                                                                                                          2
3 I/O expansion CL-LER.., CL-LET.. for logic relays CL-LM..                                                                                                                                                                 1
4 Coupler unit CL-LEC.. for remote expansion of logic relays CL-LM..
5 Memory module CL-LAS.MD003 for logic relays CL-LS.., CL-LM..                                                                                                                                                                                    3
6 Connecting cable CL-LAS.TK001, CL-LAS.TK002 to connect PC
7 CL-LINK plug CL-LAS.TK011                                                                                                                                                                            1 Display CL-LDD..
                                                                                                                                                                                                       2 Remote display connection module CL-LDC.S..
           to connect expansion to logic relays CL-LM..
8a Remote display connection module CL-LDC.S..                                                                                                                                                                    incl. connecting cable
8b Connecting cable CL-LAD.TK007                                                                                                                                                                       3 Display base module CL-LDC.L..

           to connect a remote displays to a logic relay                                                                                                                                               Communication via CL-NET
9 Display module CL-LDD..
                                                                                                                                                                                                                                     CL-.N.. ET
Expansion of logic relays*                                                                                                                                                                                                    55

1                                                                          5  2b                                                                     2CDC 312 037 F0b07                                                                     4
             4                                                         3

                                                         2a                                                                                                                                                       3                3                    2CDC 312 026 F0b06

1 Logic relay CL-LM..                                                                                                                                                                                        2                2
2 I/O expansion CL-LER.., CL-LET..                                                                                                                                                                     1                1

           2a local expansion                                                                                                                                                                          1 Display CL-LDD..
           2b remote expansion                                                                                                                                                                         2 Display base module CL-LDC.LN.. for CL-NET
3 Coupler unit CL-LEC.. for remote expansion of logic relays CL-LM..                                                                                                                                   3 Display I/O module CL-LDR.., CL-LDT..
4 CL-LINK plug CL-LAS.TK011 for expansion of logic relays CL-LM..                                                                                                                                      4 Connecting cable CL-LAD.TK002,
5 up to 30 m
                                                                                                                                                                                                                  CL-LAD.TK003, CL-LAD.TK004
     * max. 1 expansion per logic relay                                                                                                                                                                5 Termination resistor CL-LAD.TK009

                                                                                                                                                                                                       2CDC 110 004 C0210 | Catalog Electronic Products and Relays 2015 | ABB 6/4
