Logic relays Logic links instead of wiring
System overview
S1 K1 S4 S6
Concept
CL range logic relays are suitable for small and medium- T1 S5 T1 1SVC 110 000 F 0554
sized control tasks and are able to substitute logic wiring in K1 T1
a quick and simple manner.
They can be used for applications in control as well as for K2
timing functions, e.g.
– in buildings, lighting systems, air-conditioning systems, Documentation (download from the internet)
Logic relay manual: 1SVC440795M0100
general control functions, Remote display manual: 1SVC440795M2100
– in small machines and systems or Display system manual: 1SVC440795M1100
– as stand-alone control module for small applications.

Steps to the application of CL range
– CL range can be used easily, rapidly and comfortably

without any time-consuming planning and programming.
– The user can discover the advantages and the benefit of

these logic relays in no time at all.
– CL range provides for the control statements according

to a simple circuit diagram.
– Setup, storage, simulation and documentation are per-

6 formed using the compact and user-friendly CL-SOFT

software (CL-LAS.PS002).

Software characteristics (CL-SOFT)
– Display on a PC monitor according to IEC, ANSI
– Different languages to choose from
– Easy installation on all Microsoft WindowsTM operating

systems

Technical data overview Display system
– useable as compact HMI logic relay
Logic relays – fully graphic, backlit display module
– 8 or 12 digital inputs – 12 digital inputs
– 4 or 6 digital relay outputs – 4 digital relay outputs
– optionally with 4 or 8 transistor outputs – optionally with 4 transistor outputs
– 128 rungs – 256 rungs
– 3 contacts as n/o or n/c contacts in series plus 1 coil – 4 contacts as n/o or n/c contacts in series plus 1 coil

per rung per rung
– optionally with 2 or 4 analog inputs (not 100-240 V AC – optionally with 4 analog inputs (not 100-240 V AC ver-

version) sion)
– power flow display for checking the circuit diagram (de- – networking-compatible via CL-NET
– front panel mounting
vices with display) – expansion for local
– expansions for local or remote level
– enclosure color RAL 7035
– DIN rail mounting

Remote display Software
– Remote display up to a distance of 5 m – 16 timing relays 0.01-99:59 h
– Illustration of text and status displays – 16 counting relays for up-, down counting
– Remote adjustment via keypad – 8 weekly timer, 8 annual timers
– Front panel mounting – 16 analog value comparators
– 16 freely editable display texts
– 32 markers or auxiliary relays
