Logic relays
Technical data

Data at Ta = 25 °C and rated values, if nothing else indicated.

Type CL-LD...16DC2 CL-LD...17DC2 CL-LDR.16AC2
Output circuit - Analog outputs
Number - 1-
Electrical separation from voltage supply - no -
from the digital inputs - no -
Output type from the digital outputs - yes -
Signal range from PC interface, memory - yes -
Max. output current module, CL-NET, CL-LINK
Burden resistance DC voltage -
Overload and short-circuit protection - 0-10 V DC -
Resolution - 0.01 A -
- 1 k⏲ -
Setting time - yes -
Accuracy - 0.01 V DC -
analog - 10 Bit, (value: 0-1023) -
Conversion time digital - 100 ms -
- 2% -
6 General data -25...+55 °C - 1% -
Dimensions (W x H x D) 25 °C - each CPU cycle -
-
Weight
Mounting CL-LDR: 89 x 90 x 44 mm (3.5 x 3.54 x 1.73 inch) 89 x 90 x 44 mm
Mounting position CL-LDT (build-in): 89 x 90 x 25 mm (3.5 x 3.54 x 0.98 (3.5 x 3.54 x 1.73 inch)
Electrical connection inch)

CL-LDR: 0.15 kg (0.33 lb) / CL-LDT: 014 kg (0.31 lb) 0.15 kg (0.33 lb)
snap-on power supply unit
horizontal / vertical

Wire size fine-strand with wire end ferrule 0.2 mm2 / 2.5 mm2 (24-12 AWG)
Electrical connection - Data cable rigid 0.2 mm2 / 4 mm2 (24-12 AWG)

Wire size fine-strand with wire end ferrule 0.08 mm2 / 1.5 mm2 (28-12 AWG)
Environmental data rigid 0.08 mm2 / 2.5 mm2 (28-12 AWG)

Ambient temperature range operation -25...+55 °C (cold acc. to IEC 60068-2-1, heat acc. to IEC 60068-2-2)
storage -40...+70 °C
Condensation avoid condensation with suitable methods
Humidity, no condensation (IEC/EN 60068-2-30) 5-95 %
Atmospheric pressure (operation) 795-1080 hPa
Degree of protection (IEC/EN 60529) IP20
Vibration (IEC/EN 60068-2-6) 10-57 Hz (constant amplitude 0.15 mm), 57-150 Hz (constant
acceleration 2 g)
Shock (half-sine 15 g / 11 ms) (IEC/EN 60068-2-27)
Drop (IEC/EN 60068-2-31) height of fall 18 Shocks
Free fall, packaged (IEC/EN 60068-2-32) 50 mm
Insulation data 1m

Pollution degree 2
Rating of air and creepage distances EN 50178, UL 508, CSA C22.2, No. 142
Isolation resistance EN 50178

Standards

Standards and directives EN 61000-6-1/-2/-3/-4, IEC/EN 61000-4, IEC 60068-2-6, IEC 60068-2-27
Electromagnetic compatibility

electrostatic discharge (ESD) IEC/EN 61000-4-2 Level 3 (air discharge 8 kV, contact discharge 6 kV)
electromag. field (HF radiation res.) IEC/EN 61000-4-3 10 V/m
fast transients (Burst) IEC/EN 61000-4-4 Level 3 (supply cable 2 kV, signal cable 2 kV)
powerful impulses (Surge) IEC/EN 61000-4-5 2 kV (supply cable symmetrical),

HF line emission Level 2 (0.5 kV supply cable symmetrical)
Interference suppression (EN 55011, EN 55022)
IEC/EN 61000-4-6 10 V
class B
