ABB general purpose drives offer ease-of-use

ABB general purpose drives are designed to control
a wide range of applications such as pumps, fans,
conveyors and mixers, as well as process control in
industries including material handling, food and beverage,
chemical, rubber and plastics, textile and printing. The
drives are easy to select, install, configure and use,
saving considerable time as most features are built-in as
standard.

A wide power
Built-in features range for a broad
for pump and fan range of industries
applications

9
ACS310 highlights ACS550 highlights
– Designed for pump and fan applications, such as booster – Wide power range and vector control for variable and
pumps and process ventilation constant torque applications from pumps and fans to
– Compact dimensions with unified height and depth save conveyors and mixers
st
space and facilitate cabinet installations – Many built-in features including an EMC filter for 1 en-
– Equipped with pump and fan control (PFC), PID control vironment, a Modbus interface and a swinging choke
®
with booster functionality and pump protection function to enhance drive performance and help reduce the space
optimize pump or fan flow, to cut maintenance costs and needed for installation
to save energy. – Intuitive control panel and assistant functionality for fast set
up and commissioning.

Features Features
– Power range 0.37...2.2 kW (1-phase 200...240 V), – Power range 0.75...355 kW (3-phase 208...240 V,
0.37...11 kW (3-phase 200...240 V) 380...480 V)
– Power range 0.37...22 kW (3-phase 380...480 V) – Wall-mounted drives, IP21 as standard (UL type 1), IP54 as
– IP20 enclosure, optional NEMA 1 kit option (UL type 12 in frame sizes R1-R6)
– Built-in pump and fan features such as multi-pump control, – Vector control
pipe clean and fill functions – Built-in EMC filter and Modbus fieldbus interface
®
– Embedded Modbus EIA-485 – Swinging choke for superior harmonic reduction
®
– Options – Options
- Basic and assistant control panels - Basic control and assistant control panel
- Input and output chokes - Plug-in fieldbus adapters, panel mounting kits, relay out-
- Relay output extension module put extension module
- External EMC filter for 1st environment - Output chokes
- FlashDrop tool for unpowered drive configuration in - Brake units and choppers
2 seconds. - FlashDrop tool for unpowered drive configuration in
2 seconds.
