Servo drives

Analog, PTO, POWERLINK and EtherCAT options
®

MicroFlex Analog MicroFlex e100

– Compact motion control drive for single and three-phase – Compact motion control drive for single and three-phase
operation operation
– ±10 V analog speed / torque demand or Pulse + Direction – Ethernet PowerLink technology for real-time motion control
inputs – MINT programming for multitasking control of communica-
– Choice of resolver feedback or incremental encoder / SSI tions, logic, motion and HMI interaction
– Pulse Train control inputs compatible to Pulse Train Output in simple motion applications.
(PTO) module FM562 for AC500 and AC500-eCo.

Compact motion Compact motion
control drive for control drive with
simple analog or real time Ethernet
PTO control POWERLINK
technology

10

Series MicroFlex Analog Series MicroFlex e100
– 1 or 3-phase operation 105...250 V AC – 1 or 3-phase operation 105...250 V AC
– 3, 6 and 9 Arms – 3, 6 and 9 Arms
– IP20 enclosure for cabinet installation (UL open) – IP20 enclosure for cabinet installation (UL open)
– Auto-tuning and anti-resonance digital filters – Real-time Ethernet operation with PowerLink
– Suitable for single drive and multi-axis systems – Suitable for single drive and multi-axis systems
– Controls rotary and linear AC servo motors – Controls rotary and linear AC servo motors
– Options – Options
- Space saving footprint EMC filter - Space saving footprint EMC filter
- Brake units. - Brake units.
For further information, see flyer "ABB motion control For further information, see flyer "ABB motion control prod-
drives, MicroFlex brushless AC servo drives", ucts, MicroFlex e100 servo drives",
code: 3AUA0000123110 EN. code: 3AUA0000116018 EN.
