Motion controllers

MINT programmable, analog, PTO, CANopen and POWERLINK

NextMove ESB-2 NextMove e100

– Compact panel mount motion controller – Compact panel mount motion controller
– Up to 8 axes of coordinated motion – Ethernet PowerLink technology for real-time motion control
– Stepper and analog axis control – Stepper and analog axis control
– CANopen manager for system expansion – CANopen manager for system expansion
– MINT programming for multitasking control of communica- – MINT programming for multitasking control of communica-
tions, logic, motion and HMI interaction in simple motion tions, logic, motion and HMI interaction in simple motion
applications. applications.

Compact motion Compact motion
controller for controller with
analog and real-time Ethernet
stepper control POWERLINK
technology

10

Series NextMove ESB-2 Series NextMove e100
– Up to 8 axes of coordinated motion – 1 to 16 axes interpolated axes via POWERLINK
– 4 x PTO (Stepper) axes – Additional CN profiled POWERLINK axes
– 3 or 4 x analog controlled axes with encoder feedback – 4 x PTO (stepper) axes
– Maximum of 8 axes of control – 3 x analog controlled axes with encoder feedback
– Digital and analog I/O including 4 x high speed registration – Maximum of 30 axes of control
latches – Digital and analog I/O including 4 x high speed registration
– Options latches
- RS232 or RS485 serial option – Options
- Differential / single-ended stepper interfaces - Differential / single-ended stepper interfaces
- 7 axis or 8 axis variants. - 8, 12 or 16 axes of interpolated motion.
