AC500

High performance modular PLC

Communication interface modules
Number of Input signal Output Output signal Terminal units Type Order code Price Weight
type Screw / Spring (1 pce)
AI/AO/DI/DO/DC kg
Communication interface module for FieldBusPlug
- / - / 8 / - / 8 24 V DC Transistor 24 V DC, 0.5 A TU505-FBP / DC505-FBP 1SAP220000R0001 0.200
TU506-FBP
Communication interface module for CS31-Bus
DC505-FBP - / - / 8 / - / 16 24 V DC Transistor 24 V DC, 0.5 A TU551-CS31 / DC551-CS31 1SAP220500R0001 0.200
TU552-CS31
- / - / - / - / 16 24 V DC Transistor 24 V DC, 0.5 A TU551-CS31 / CI590-CS31-HA 1SAP221100R0001 0.200
TU552-CS31
4 4 / 2 / 8 / - / 8 24 V DC/ Transistor 24 V DC, 0.5 A/ TU551-CS31 / CI592-CS31 1SAP221200R0001 0.200
0…10 V, -10…+10 V, TU552-CS31
-10…+10 V, 0…20 mA,
0…20 mA, 4…20 mA
4…20 mA,
PT100, PT1000,
Ni100, Ni1000
Communication interface module for PROFIBUS -DP
®
4 / 2 / 8 / 8 / - 24 V DC/ Transistor 24 V DC, 0.5 A/ TU509/TU510/ CI541-DP 1SAP224100R0001 0.200
0…10 V, -10…+10 V, TU517/TU518
-10…+10 V, 0…20 mA,
0…20 mA, 4…20 mA (1)
CI541-DP
4…20 mA,
PT100, PT1000,
Ni100, Ni1000
- / - / 8 / 8 / 8 24 V DC Transistor 24 V DC, 0.5 A TU509/TU510/ CI542-DP 1SAP224200R0001 0.200
TU517/TU518
Communication interface module for CANopen ®
4 / 2 / 8 / 8 / - 24 V DC/ Transistor 24 V DC, 0.5 A/ TU509/TU510/ CI581-CN 1SAP228100R0001 0.200
0…10 V, -10…+10 V, TU517/TU518
-10…+10 V, 0…20 mA,
0…20 mA, 4…20 mA
4…20 mA,
PT100, PT1000,
Ni100, Ni1000
- / - / 8 / 8 / 8 24 V DC Transistor 24 V DC, 0.5 A TU509/TU510/ CI582-CN 1SAP228200R0001 0.200
TU517/TU518
CI511-ETHCAT Communication interface module for Ethernet based protocol - EtherCAT ®
4 / 2 / 8 / 8 / - 24 V DC/0…10 V, Transistor 24 V DC, 0.5 A / TU507-ETH / CI511-ETHCAT 1SAP220900R0001 0.200
-10…+10 V, -10…+10 V, TU508-ETH
0…20 mA, 0…20 mA,
4…20 mA, 4…20 mA
PT100, PT1000,
Ni100, Ni1000
- / - / 8 / 8 / 8 24 V DC Transistor 24 V DC, 0.5 A TU507-ETH / CI512-ETHCAT 1SAP221000R0001 0.200
TU508-ETH
Communication interface module for Ethernet based protocol - PROFINET IO RT
®
4/2/8/8/- 24 V DC/0…10 V, Transistor 24 V DC, 0.5 A/ TU507-ETH / CI501-PNIO 1SAP220600R0001 0.200
-10…+10 V, -10…+10 V, TU508-ETH
0…20 mA, 0…20 mA,
4…20 mA, 4…20 mA
PT100, PT1000,
Ni100, Ni1000
CI501-PNIO
-/-/8/8/8 24 V DC Transistor 24 V DC, 0.5 A TU507-ETH / CI502-PNIO 1SAP220700R0001 0.200
TU508-ETH

From To Output signal Terminal units Type Order code Price Weight
(1 pce)
kg
Communication interface module gateway on Ethernet based protocol - PROFINET IO RT
®
®
PROFINET I/O – 3 x RS232/485 TU520-ETH CI504-PNIO 1SAP221300R0001 0.200
ASCII serial
interfaces
CI504-PNIO PROFINET I/O 1x CAN 2A/2B or CANopen 2 x RS232/485 TU520-ETH CI506-PNIO 1SAP221500R0001 0.200
®
®
Master ASCII serial
interfaces
