Powder coated enclosures for indoor use

KSIK

KSIK enclosures are designed for indoor use, environment
classes C and C *. An enclosure with a high degree of
1 2
protection, well suited for installations in industry and in
buildings.

The enclosure is developed for distribution boards and
3 therefore has special openings in its sides to allow
busbar systems to pass through where more than one
enclosure is combined.

− Supplied complete with wall brackets and mounting plate.
− Powder coated.
− Side-hung doors.
− Removable mounting plate.
− Split base plate.
− Degree of protection IP34D.
KSIK 048
Note:
Busbar systems for 400 A-1600 A on request.

* To ISO 12944-2
C : Heated, dry room
1
C : Small amounts of humidity may occur.
2

Designation ID No. Qty flange openings FL 21 in Number of Dimensions Weight
the base plate modules Height Width Depth
M * mm kg/pcs
KSIK 043 2CGX0 63300411 4 43 900 655 325 42
KSIK 063 2CGX0 63300412 6 63 900 895 325 57
KSIK 098 2CGX0 63300413 10 98 900 1350 325 75
* One module M = 12.5 mm.

The enclosure includes
Content Enclosure KSIK
Mounting plate Yes
Key shape for lock DIN 3
Two covered flange openings, size FL 33 in each side panel. Yes
Base plate with FL 21 flange openings Yes
Split base plate Yes
Busbar system On request

3/11 | 2016 | Kabeldon fusegear and cable distribution cabinets | Enclosures |
