Page 319 - Entrelec Terminal Blocks Master Catalog

D4/6.D2.ADO IDC terminal blocks
Double deck ADO - screw clamp - 6 mm 0.236 in spacing

Description
1.5 mm²
– Save space with 2 decks terminal block,
16 AWG – With the TE Connectivity ADO System , experience the fastest and most reliable connection on the market,
®
– This solution brings all the benefits of the ADO System and allows installators to connect on standard screw
®
clamp,
– Up to 2 wires per connection in the ADO System connection.
®
Ordering details Color Type Part Number Pkg Weight
Description
1SNC163035F0014 Feed-through With 2 feed-through Grey D4/6.D2.ADO 1SNA199242R0200 pce (1 pce) g
18.00
50
circuits
18.00
1SNA199244R0400
D4/6.D2.N.ADO
Blue
50
Main technical data Mounting instructions
2
IEC UL CSA Rail TH 35-7.5,
TH 35-15
ADO Rigid: Solid/Stranded 0.28-1.5 mm² 22-16 AWG Wire stripping 9.5 mm
D4/6.D2.ADO Flexible without ferrule 0.34-1.5 mm² length 0.37 in
Screw clamp Rigid: Solid/Stranded 0.2-4 mm² 22-10 AWG Tool Flat screwdriver
Flexible without ferrule 0.22-4 mm² Ø 4 mm
85.3 3.36" Flexible with insulated ferrule Ø 0.157 in
Gauge A4
Rated current / Rated cross section 17.5 A / 1.5 mm² 18 A / 16 AWG
Rated short-time withstand current (1s) 180 A Torque 0.5 - 0.8 N.m
83 3.27" 75.5 2.97" Rated voltage 800 V 600 V 4.4 - 7.1 lb.in
6000 V
Impulse withstand voltage
Protection IP20 NEMA 1
The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
C US
44.8 1.76" RoHS cCSAus Gost R
6 mm 0.236 in spacing

Accessories
Description Color Type Part Number Pkg Weight
pce (1 pce) g
1 2
1 End stops 10 mm 0.394 in Dark grey BAZH1 1SNK900102R0000 20 24.00
2 End sections 5 mm 0.197 in Grey FED2AD1 1SNA199417R1200 20 6.60
3 Jumper bars 2 poles 32 A BJMI6-2 1SNA176663R0000 10 4.40
3 poles BJMI6-3 1SNA176664R0100 10 6.70
3 4 4 poles BJMI6-4 1SNA176665R0200 10 8.90
5 poles BJMI6-5 1SNA176666R0300 10 11.20
10 poles BJMI6-10 1SNA176667R0400 10 22.40
4 Lateral jumper bars 2 poles 35 A Grey PC6-2 1SNA113546R1400 10 2.00
10 poles PC6-10 1SNA113548R2600 10 8.00
5 6
5 Insulating tips For lateral jumper bars type PC... EIP 1SNA113550R2400 10
6 Circuit separators 0 mm 0 in Grey SCAD 1SNA196896R0000 10
7 Shield connectors CBD2S 1SNA178408R1400 50
8 Tools Semi automatic tool OUPAD 1SNA178944R0400 1 205.00
7 8 Hand tool OUMAD 1SNA179466R0600 1 29.00
9 Terminal block markers Blank card White RC610 1SNA233000R0100 1 7.50
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.
9

1SNC163007S0201 - Rev. A
Ground
Description Color Type Part Number Pkg Weight
pce (1 pce) g
Ground Profile aligned with D4/6.D2 ADO Green-yellow D4/6.D1.P.ADO 1SNA399931R2500 50 23.00

Technical data valid for copper conductors only.

PAGE 27
