M70/31.FF stud terminal blocks
Feed-through - 31 mm 1.220 in spacing

Description
50 mm²
– Compact two stud terminal block,
00 AWG – Lug mounting in accordance with NF C 20-130 and DIN 46234,
– Various marking options,
– Rail or base mounting.
Ordering details
Description Color Type Part Number Pkg Weight
(1 pce) g
1SNC165006F0014 Feed-through 2 studs M8 linked Grey M70/31.FF 1SNA115143R1200 10 110.00
pce
by 1 removable
bar 20 x 5 mm
Main technical data Mounting instructions
NFC DIN UL CSA Rail G32, TH 35-7.5,
Lugs Rigid: Solid/Stranded 6-70 mm² 2.5-70 mm² 4-00 AWG max 0 AWG TH 35-15
Flexible with JOTVMBUFE GFSSVMF 6-50 mm² 2.5-50 mm² Lugs Wrench
M70/31.FF
Gauge C5 Tool H13 mm
IEC DIN UL CSA Torque 6-12 N.m
Screw clamp Rigid: Solid/Stranded 53.1-106.2 lb.in
66 2.60" Flexible without ferrule Jumper screw
22 0.87" Gauge Tool
66 2.60" IEC DIN UL CSA Torque 4
63.5 2.50" Bar 20 x 5 mm 0.78 x 0.20 in 175 A 200 A Screw clamp
Rated current
150 A
178 A
58.5 2.30" Rated cross section 50 mm² 50 mm² 00 AWG 0 AWG Tool
1000 V
600 V
600 V
Rated voltage
8000 V
Torque
Impulse withstand voltage
34 1.34"
Wire stripping
39 1.54"
length
The connecting capacity data for one Rigid: Solid/Stranded, or one Flexible conductor (when applicable) is a mandatory information required by IEC, UL and CSA standards (Copper conductors).
31 mm 1.220 in spacing All other data are provided as supplementary information only. For more details, please consult our CB, UL or CSA certificates and technical datasheet available on http://www.TE.com
RoHS USR CSA Gost R
Accessories
Description Color Type Part Number Pkg Weight
pce (1 pce) g
1 2 1 End stops 9.1 mm 0.358 in Grey BAMH 1SNA114836R0000 50 13.00
10 mm 0.394 in Dark grey BAZH1 1SNK900102R0000 20 24.00
2 Circuit separators Circuit separators Grey ECP31 1SNA113690R2100 10 6.70
3 Protecting covers Transparent CPP311 1SNA168204R1500 5 7.00
3 4 marked cut: 2 blocks CPP312 1SNA168203R1400 5 14.00
marked cut: 3 blocks CPP313 1SNA163409R0600 5 23.00
4 Terminal block Label holder Grey PEP 1SNA113762R2400 50 0.46
markers Terminal block markers White RC610 1SNA233000R0100 1 7.50
Complete list of accessories is indicated in the terminal block datasheet.
Some accessories such as jumper bars may modify the terminal block’s ratings: complete information in the accessories catalogue pages.

1SNC165020S0201 - Rev. B

Technical data valid for copper conductors only.
