End sections
Terminal blocks accessories

E-RGW2.5 end sections
Description
1SNC160465V0014 Ordering details
– End section compatible with RGW2.5... and RGW2.5-T... terminal block

Description
Part Number
Type
Weight
Color
Pkg
qty (1 pce) g
1.2 mm 0.047 in spacing Grey E-RGW2.5 1SNA519003R0000 25 1.89
E-RGW2.5
E-RGW6 end sections
Description
1SNC160466V0014 Ordering details
– End section compatible with RGW6... and RGW6-T... terminal block

Weight
Part Number
Type
Pkg
Description
Color
qty (1 pce) g
1.4 mm 0.0551 in spacing Grey E-RGW6 1SNA519004R0000 50 2.65
E-RGW6
E-RGW6-ST end sections
Description
1SNC160467V0014 Ordering details
– End section compatible with RGW6-ST-1… and RGW6-R1... terminal block

Description Color Type Part Number Pkg Weight
qty (1 pce) g
1.4 mm 0.0551 in spacing Grey E-RGW6-ST 1SNA519004R0100 25 5.18
E-RGW6-ST

E-RGW25 end sections

Description
1SNC160468V0014 Ordering details
– End section compatible with RGW25... terminal block

Type
Part Number
Color
Pkg
Description
Weight
qty (1 pce) g
1.4 mm 0.0551 in spacing Grey E-RGW25 1SNA519005R0000 25 0.146
E-RGW25
Main technical data
Material specifications Insulating material Polyamide
Flammability V0
NF F 16 101 I2F2
Ambient temperature Service IEC 60068-2-1 -40 ... +100 °C -40 ... +212 °C
min/max Storage -40 ... +100 °C -40 ... +212 °C
Installing -25 ... +70 °C -13 ... +167 °C
All the main technical data provided are "manufacturer" values.
1SNC168035S0201
CE RoHS

Technical data valid for copper conductors only.
