Page 238 - Motor_protection_and_control_Manual_motor_starters_ contactors

DOL starters protected by MCCB (magnetic only) and

electronic overload relays
With AF contactors - Open type version in kit form

Main dimensions mm, inches
12 x
105 4.13" 152 5.98" 35 1.39" M5 10-24 UNC

176 6.93"

5

39.5 1.56"

556.5 21.91"

165 6.50"

20.5 0.81"

112 4.42"

T4S
+ BEA205/T4
+ AF190, AF205
+ EF205 electronic overload relay

1SFC101194C0201
