DOL starters protected by MCCB (magnetic only) and

electronic overload relays
With AF contactors - Open type version in kit form

Main dimensions mm, inches
12 x
140 5.51" 180 7.09" 46.5 1.83" M5 10-24 UNC

176 6.93"

5

45 1.77"

600.5 23.64"

187 7.36"

29 1.14"

112 4.41"

35 1.38"
43.75 1.72"
T5S
+ BEA370/T5
+ AF265, AF305, AF370
+ EF370 electronic overload relay

1SFC101195C0201

ABB | 5/39
