Mounting plates

Description
Mounting plates with fixing holes for the specified 3-pole contactors and overload relays.

1SFC101087V0001 Ordering details For Type Order code Pkg Weight
For 3-pole contactors
overload relays
qty
(1 pce)
kg
PN460
Mounting plates for Direct on line starters
AF400, AF460 E500DU PN460-11 1SFN095705R1000 1 2.120
AF580, AF750 E800DU PN750-11 1SFN096105R1000 1 2.500

For two contactors side For one or two Type Order code Pkg Weight 5
by side with space for overload relays qty (1 pce)
mechanical interlock
kg
Mounting plates for mechanical interlocked contactors, reversing starters and two speed starters for
double windings
AF400, AF460 E500DU PN460-21 1SFN095701R1000 1 3.490
AF580, AF750 E800DU PN750-21 1SFN096101R1000 1 4.230

For main For star For Type Order code Pkg Weight
and delta contactors contactor (1) overload relays qty (1 pce)
kg
Mounting plates for star-delta starters and two speed starters for single windings
AF400, AF460 A300, AF400 E500DU PN460-41 1SFN095703R1000 1 5.310
AF580, AF750 AF400 ... AF580 E800DU PN750-41 1SFN096103R1000 1 6.320
(1) Space for mechanical interlock included.
