AS09..S ... AS16..S and

ASL09..S ... ASL16..S 3-pole contactors - with spring terminals
Main accessories

Front-mounted instantaneous auxiliary contact blocks
1SBC101037F0014 For contactors Auxiliary Type Order code Pkg Weight
(1 pce)
contacts
qty

kg
CA3-10S
AS09..S … AS16..S 1 0 CA3-10S 1SBN011019T1010 10 0.011
ASL09..S … ASL16..S 0 1 CA3-01S 1SBN011019T1001 10 0.011

1SBC101069F0014 Mechanical interlock unit Type Order code Pkg Weight
For contactors
(1 pce)
qty
kg
VM3
AS09..S … AS16..S, ASL09..S … ASL16..S VM3 1SBN031005T1000 10 0.002
6
Surge suppressors
1SBC574001F0301 For contactors Rated control circuit Type Order code Pkg Weight
(1 pce)
qty
voltage - Uc
V AC DC kg
RV5 AS09..S ... AS16..S, 24...50 ● ● RV5/50 1SBN050010R1000 2 0.015
ASL09..S ... ASL16..S 50...133 ● ● RV5/133 1SBN050010R1001 2 0.015
110...250 ● ● RV5/250 1SBN050010R1002 2 0.015
250...440 ● ● RV5/440 1SBN050010R1003 2 0.015
AS09..S ... AS16..S 24...50 ● – RC5-1/50 1SBN050100R1000 2 0.012
50...133 ● – RC5-1/133 1SBN050100R1001 2 0.012
110...250 ● – RC5-1/250 1SBN050100R1002 2 0.012
250...440 ● – RC5-1/440 1SBN050100R1003 2 0.012
ASL09..S ... ASL16..S 12...32 – ● RT5/32 1SBN050020R1000 2 0.015
25...65 – ● RT5/65 1SBN050020R1001 2 0.015
50...90 – ● RT5/90 1SBN050020R1002 2 0.015
77...150 – ● RT5/150 1SBN050020R1003 2 0.015
150...264 – ● RT5/264 1SBN050020R1004 2 0.015
1SBC101384F0010
BEA16-3U

Connecting links with manual motor starters
For contactors Manual motor Type Order code Pkg Weight
starter qty (1 pce)
kg
AS09..S ... AS16..S MS116-0.16 ... MS116-16 BEA16-3U 1SBN081020R1000 1 0.045
ASL09..S ... ASL16..S MS132-0.16 ... MS132-16

1SBC101412S0201
