AF09..S ... AF26..S 3-pole contactors - with spring terminals

4 to 11 kW
AC / DC operated

Description
AF09..S ... AF26..S contactors are mainly used for controlling 3-phase motors and power circuits up to
690 V AC and 220 V DC. These contactors are of the block type design with 3 main poles:
– control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage
range (e.g. 100...250 V AC and DC), only 4 control voltage ranges covering 24...500 V 50/60 Hz and
1SBC101099F0014 - can manage large control voltage variations
20...500 V DC
- reduced panel energy consumption
- very distinct closing and opening.
AF09-30-10S – built-in surge suppression
– add-on auxiliary contact blocks for front or side mounting and a wide range of accessories.
Ordering details
IEC UL/CSA Rated control circuit Auxiliary Type Order code Weight
Rated operational 3-phase General voltage contacts
power current motor use Uc min. … Uc max. fitted Pkg
θ≤ 40 °C rating rating (1 pce)
400 V 480 V 600 V AC
AC-3 AC-1
kW A hp A V 50/60 Hz V DC kg
6 4 22 5 20 24...60 - (1) 1 0 0 1 AF09-30-10S-41 1SBL137004R4110 0.270
1SBC101100F0014 48...130 48...130 1 0 0 1 AF09-30-10S-12 1SBL137004R1210 0.270
1SBL137004R4101
AF09-30-01S-41
0.270
0.270
AF09-30-01S-12
1SBL137004R1201
100...250
100...250
1SBL137004R1301
0 1 0 1 AF09-30-10S-13 1SBL137004R1310 0.270
0.270
AF09-30-01S-13
AF26-30-00S 250...500 250...500 1 0 AF09-30-10S-14 1SBL137004R1410 0.310
0 1 AF09-30-01S-14 1SBL137004R1401 0.310
5.5 24 7.5 20 24...60 - (1) 1 0 AF12-30-10S-41 1SBL157004R4110 0.270
0 1 AF12-30-01S-41 1SBL157004R4101 0.270
48...130 48...130 1 0 AF12-30-10S-12 1SBL157004R1210 0.270
0 1 AF12-30-01S-12 1SBL157004R1201 0.270
100...250 100...250 1 0 AF12-30-10S-13 1SBL157004R1310 0.270
0 1 AF12-30-01S-13 1SBL157004R1301 0.270
250...500 250...500 1 0 AF12-30-10S-14 1SBL157004R1410 0.310
0 1 AF12-30-01S-14 1SBL157004R1401 0.310
7.5 24 10 20 24...60 - (1) 1 0 AF16-30-10S-41 1SBL177004R4110 0.270
0 1 AF16-30-01S-41 1SBL177004R4101 0.270
48...130 48...130 1 0 AF16-30-10S-12 1SBL177004R1210 0.270
0 1 AF16-30-01S-12 1SBL177004R1201 0.270
100...250 100...250 1 0 AF16-30-10S-13 1SBL177004R1310 0.270
0 1 AF16-30-01S-13 1SBL177004R1301 0.270
250...500 250...500 1 0 AF16-30-10S-14 1SBL177004R1410 0.310
0 1 AF16-30-01S-14 1SBL177004R1401 0.310
11 35 – – 24...60 - (1) 0 0 AF26-30-00S-41 1SBL237004R4100 0.320
48...130 48...130 0 0 AF26-30-00S-12 1SBL237004R1200 0.320
100...250 100...250 0 0 AF26-30-00S-13 1SBL237004R1300 0.320
250...500 250...500 0 0 AF26-30-00S-14 1SBL237004R1400 0.360
(1) For 24...60 V 50/60 Hz - 20...60 V DC, use AF..-30-..S-11 (see voltage code table).
AF..-30-..S-11 not suitable for direct control by PLC-output.

Main dimensions mm, inches
77 3.03" 86 3.38"
45 1.77" 71 2.79" 45 1.77" 80 3.15"
5.5 5.5
0.22" 0.22"
11.5 0.45" 10 0.39"
80 3.15" 35 mm EN/IEC 60715 5.5 0.22" 82.5 3.24" 35 mm EN/IEC 60715 5.5 0.22"

10 0.39" 10 0.39" 1SBC101688S0201 - Rev. A
AF09..S, AF12..S, AF16..S AF26..S
