Page 675 - Motor_protection_and_control_Manual_motor_starters_ contactors

AF09..S ... AF26..S 3-pole contactors - with spring terminals

Main accessories

Ordering details (1)
For contactors Auxiliary Type Order code Pkg Weight
contacts
qty
(1 pce)
1SBC101110F0014 kg
CA4-10S Front-mounted instantaneous auxiliary contact blocks
AF09..S ... AF26..S 1 1 0 0 CA4-10S 1SBN010119R1010 1 10 0.016
CA4-10S-T 1SBN010119T1010
0.016
1SBC101125F0014 0 0 2 1 1 2 CA4-01S 1SBN010119R1001 1 10 0.016
CA4-01S-T 1SBN010119T1001
0.016
1
1SBN010145R1122
0.060
CA4-22MS
CA4-22MS AF09 ... AF16..-30-10S 3 1 CA4-31MS 1SBN010145R1131 1 0.060
AF26..S 2 2 CA4-22ES 1SBN010145R1022 1 0.060
3 1 CA4-31ES 1SBN010145R1031 1 0.060
4 0 CA4-40ES 1SBN010145R1040 1 0.060
1SBC101113F0014 Side-mounted instantaneous auxiliary contact blocks
1
1
1
CAL4-11S
AF09..S ... AF26..S
1SBN010130R1011
0.045
6
CAL4-11S
Front-mounted instantaneous auxiliary contact and A1/A2 coil terminal blocks
AF09 ... AF16..-30-10S 1 1 CAT4-11MS 1SBN010153R1111 1 0.045
AF26..S 1 1 1 1 CAT4-11ES 1SBN010153R1011 1 1 0.045
1SBC101117F0014 Note: CAT4 not fittable on AF..Z contactors with DC control voltage 12…20 V DC.
AF09 ... AF16..-30-01S
CAT4-11US 1SBN010153R1311
0.045
CAT4-11ES
Ordering details (1)
For contactors Time delay Delay Rated control Auxiliary Type Order code Pkg Weight
range type circuit voltage contacts qty (1 pce)
selected by Uc
switch
1SBC101393F0014 Front-mounted electronic timer V 50/60 Hz or DC kg
AF09..S ... AF26..S 0.1...1 s ON-delay 24...240 1 1 TEF4S-ON 1SBN020113R1000 1 0.065
TEF4S-OFF 1...10 s OFF-delay 24...240 1 1 TEF4S-OFF 1SBN020115R1000 1 0.065
10...100 s
1SBC101128F0014
VM4 Ordering details (1)
1SBC101135F0014 For contactors Type Order code Pkg Weight
qty
(1 pce)

1SBC101136F0014 Mechanical interlock unit VM4 1SBN030105T1000 10 0.005
LDC4S kg
AF09..S ... AF26..S
1SBC101138F0014 BX4 Note: VM4 includes 2 fixing clips (BB4) to maintain together both contactors.

Additional coil terminal block
BX4-CA AF09..S ... AF26..S LDC4S 1SBN070157T1000 10 0.010
Protective covers
All 1-stack contactors BX4 1SBN110108T1000 10 0.006
For 4-pole CA4..S and 2-pole CAT4..S auxiliary contact blocks BX4-CA 1SBN110109W1000 50 0.001
(1) See "Main accessory fitting details" table.
Note: Following accessories can be used on 3-pole contactors AF09 ... AF96 with screw terminals :
- 1 or 4-pole CA4...S auxiliary contact blocks
- 2-pole CAL4-11S auxiliary contact blocks
- TEF4S electronic timer 1SBC101703S0201 - Rev. A
- LDC4S coil terminal block.

ABB | 6/51
