AF50 ... AF75 3-pole contactors

Main dimensions mm, inches

35 mm x 15 EN/IEC 60715
2 6 0.24" 108 4.25" 6.5 0.26" ø 6.2 0.24"
(M6)

110 4.33" 0.16" 90 3.54" 100 3.94"
4
75 mm EN/IEC 60715

70 2.76" 10 0.39" 10 0.39" 5 0.20" 60 2.36" 5 0.20"
AF50, AF63, AF75 AF50, AF63, AF75

133.9 5.27" 108 4.25"
35 mm x 15 EN/IEC 60715 6 0.24" 6.5 0.26" 35 mm x 15 EN/IEC 60715 6 0.24" 6.5 0.26"
108 4.25"

110 4.33" 0.16" 47 1.85" 74 2.91" 110 4.33" 4 0.16"
4
75 mm EN/IEC 60715 75 mm EN/IEC 60715

70 2.76" 10 0.39" 10 0.39" 12 0.47" 70 2.76" 10 0.39" 10 0.39"
AF50, AF63, AF75 AF50, AF63, AF75
+ CA5 front mounted 1-pole auxiliary contact block + CAL5 side mounted 2-pole auxiliary contact block
140.3 5.52"
35 mm x 15 EN/IEC 60715 6 0.24" 108 4.25" 6.5 0.26"

110 4.33" 4 0.16" 47 1.85"
75 mm EN/IEC 60715

70 2.76" 10 0.39" 10 0.39"
AF50, AF63, AF75
+ CA5 front mounted 4-pole auxiliary contact block 108 4.25"

35 mm x 15 EN/IEC 60715 6 0.24" 6.5 0.26" 5 0.20" ø 6.2 0.24"
(M6)

110 4.33" 4 0.16" 90 3.54" 100 3.94"
75 mm EN/IEC 60715 5 0.20"

155 6.10" 10 0.39" 10 0.39" 5 0.20" 60 2.36" 85 3.35" 5 0.20"
1SBC100139S0201 - Rev. A
AF50, AF63, AF75 AF50, AF63, AF75
+ VE5-2 electrical and mechanical interlock unit + VE5-2 electrical and mechanical interlock unit

Note: contactor lateral distance to grounded component 2 mm 0.08" min.
