AF190B, AF205B 3-pole contactors
Main dimensions mm, inches
210 8.27" 152 5.98"
2
196 7.727"
AF190B, AF205B-30-22
+ VM19 mechanical interlocking unit
6 X
35 1.38" 70 2.76" 35 1.38" M5 10-24 UNC
165 6.50"
AF190B, AF205B-30-22
+ VM19 mechanical interlocking unit
1SFC101282C0201
