3/394 ABB MOTOR PROTECTION AND CONTROL

—

AF80 4-pole contactors
Dimensions

116 4.57" 80 3.15"
90 3.54" 2 x
7 0.28" ø 6.4 0.25" M6 ¼-20 UNC
03
6 0.24"
35 x 15 mm EN/IEC 60715
119.5 4.70" 5.5 0.22" 110 4.33" 100 3.94"

4.6 0.18"

10 0.39"
5 0.20"
AF80 AF80

149 5.87"
116 4.57" 10 116 4.57"
90 3.54" 0.39" 12 0.47" 90 3.54"
7 0.28" 7 0.28"
6 0.24" 6 0.24"
5.5 0.22"
35 x 15 mm EN/IEC 60715 35 x 15 mm EN/IEC 60715
119.5 4.70" 5.5 0.22" 43 1.69" 119.5 4.70"

10 0.39"
AF80 AF80
+ CA4, CC4 1-pole auxiliary contact block + CAL4-11 2-pole auxiliary contact block

149 5.87" 171.8 6.76"
116 4.57" 10 116 4.57" 10
90 3.54" 0.39" 90 3.54" 0.39"
7 0.28" 7 0.28"
6 0.24" 6 0.24" 1.1 0.04"

35 x 15 mm EN/IEC 60715 35 x 15 mm EN/IEC 60715
119.5 4.70" 5.5 0.22"" 43 1.69" 119.5 4.70" 5.5 0.22"" 40.5 1.59"
0.22
5
.5
0.22
5
.5
AF80 AF80
+ CA4 4-pole auxiliary contact block + TEF4 Electronic timer

1SBC101978S0201

Main dimensions mm, inches
