AF116, AF140 4-pole contactors
Dimensions

SECTION A-A
A
10 0.39" 120 4.72" 128 5.04" 60 2.36" M4 8-32 UNC
03

55.5 0.22" 19.5 4.96"

150 5.91" 100 3.94"

30 1.18"
AF116, AF140-40-00 + CAL19 2-pole auxiliary contact block AF116, AF140-40-..(B)
AF116, AF140-40-11

A SECTION A-A
10 0.39" 120 4.72" 128 5.04"

55.5 2.18" 19.5 0.77"

150 5.91"

30 1.18"
AF116, AF140-40-00B + CAL19 2-pole auxiliary contact block
AF116, AF140-40-11B

240 240 9.45" 128 128 5.04"
9.45"
5.04"
60 2.36" 60 2.36" 60 2.36" M4 8-32 UNC

150 5.91" 150 5.91" 100 3.94"

AF116, AF140-40-11 AF116, AF140
+ VM19 mechanical interlocking unit + VM19 mechanical interlocking unit
1SFC101228C0201 - Rev. A

Main dimensions mm, inches
